Model No
|
T22DW
|
T215DW
|
T19DW
|
T156DW
|
|
|
Screen panel
|
SIZE
|
22"
|
21.5"
|
19"
|
15.6"
|
|
Aspect Ratio
|
16:9
|
16:9
|
16:10
|
16:9
|
|
|
Active area (HxV)
|
476.64*268.11
|
476.64*268.11
|
408.24 * 255.15
|
344.232 * 193.536
|
|
|
Pixel pitch (HxV)
|
0.24825X0.24825
|
0.24825X0.24825
|
0.2835X0.2835
|
0.252X0.252
|
|
|
Native resolution
|
1920 x 1080
|
1920 x 1080
|
1440 x 900
|
1920 x 1080
|
|
|
Response time
|
18ms (typ)
|
5ms
|
5ms
|
8 ms
|
|
|
Viewing angle
|
H:170°, V: 160°
|
H:170°, V: 160°
|
H:170°, V: 160°
|
H:70°/70°, V:60°/60°
|
|
|
Brightness
|
250cd/㎡
|
250cd/㎡
|
250cd/㎡
|
250cd/㎡
|
|
|
Contrast ratio
|
3000:1
|
1000:1
|
1000:1
|
800:1,
|
|
|
Colour
|
16.7M
|
16.7M
|
16.7M
|
16.7M
|
|
|
Electrical Features
|
Frequency (H/V)
|
30~64kHz; 56~60Hz
|
30~81kHz;56~75Hz
|
0~81kHz; 56~75Hz
|
30~64 kHz; 56~60Hz
|
|
Pixel frequency
|
140 MHz
|
140 MHz
|
140 MHz
|
85 MHz
|
|
|
Video input (R/G/B)
|
0.7 Vpp / 75 ohms
|
0.7 Vpp / 75 ohms
|
0.7 Vpp / 75 ohms
|
0.7 Vpp / 75 ohms
|
|
|
Power supply
|
Input 100-240 VAC, 50/60Hz, Output:12VDC 3A ( (Adapter)
|
||||
|
Interactive Technology
|
Technology
|
Electromagnetic technology, support WIN 7 / 8 / 10 OS, MAC OS … etc
|
|||
|
Tablet Resolution
|
2540Lpi
|
2048Lpi
|
4000Lp
|
5080Lpi
|
|
|
Pen pressure
|
2048 Levels
|
2048 Levels
|
2048levels
|
2048 Levels
|
|
|
Reading accuracy
|
±0.5 mm (center)
|
±0.5 mm (center)
|
±0.5 mm (center)
|
±0.5 mm (center)
|
|
|
Detectable tilt range
|
±50°
|
±50°
|
±45°
|
Tilt 45°
|
|
|
Tracking speed
|
200 PPS
|
133pps
|
133pps
|
130pps
|
|
|
Interfaces
|
USB interface
|
USB*1; VGA*1, DVI*1, HDMI*1
|
USB*1; VGA*1, DVI*1, HDMI*1
|
USB*1; VGA *1, DVI*1
|
USB*1; HDMI*1
|
|
Shortcut keys
|
8keys/side ( as photo)
|
-
|
-
|
-
|
|
|
Display buttons
|
5 buttons
|
5 buttons
|
5 buttons
|
5 buttons
|
|
|
Environment
|
T & H condition
|
5-35℃,20-80%RH; -10-55℃,10-90%RH (power off)
|
|||
|
Physical Specs
|
Screen Protection
|
Tempered Glass
|
Tempered Glass
|
Tempered Glass
|
Tempered Glass
|
|
VESA Stand
|
Option
|
Option
|
Option
|
Option
|
|
|
pen package
|
The rechargeable pen / Pen with batterry nibs, pen holder
|
||||
|
Dimension (W*H*D)
|
429x372x56mm
|
520x340x62mm
|
452x319.5x 62mm
|
362x295x 16.6 mm
|
|
|
Weight
|
N.W:3.4kg, G.W4.3kg
|
N.W:4.52kg, G.W5.42kg
|
N.W:4.2kg, G.W5.1kg
|
N.W:2.1kg, G.W3.4kg
|
|
|
Packages
|
Package dimension
|
||||
|
Package Weight
|
|||||
|
Accessories
|
Power cord, USB cable, VGA/DVI/HDMI*1 (per the interfaces of the unit); pen*1, CD *1, Manual*1
|
||||
|
Compliance
|
CE, FCC, ROHS
|
||||
