Factory made strictly checked lcd display touch standee signage touch flexible display
ITATOUCH LCD digital signage adopt LED backlight screen panel with FHD 1080P resolution, include wall mounted and floor stand installation, it has Android and PC LAN version, card reader version option.
The materials of the case are aluminum frame with drawing painted treatment and metal backside, front panel usually is metal panel with painted color, and covered edge finish.
Interactive touch screen option – infrared multi touch or capacitive touch technology.
ITATOUCH support the customized device, include color, configuration, shape and functions. OEM welcome!
* 1080P Full HD Display
* Sunshine sight, high brightness, 1500 ~2000cd option.
* Support LAN management documents by Remote Control
* Support flash subtitle, Log management, time on/off
* Multi-display modes; Horizontal, Vertical, Full and Divided displaying
* Security Design, industrial mainboard, and tempered glass
* Support full media format files
Hardware & SoftwareHardware: Aluminum Frame with Metal / Plastic painting color, support customized shape
Net-working management software
Each terminal/unit installed, the managment software to be installed computer sever if needs.
Horizontal Outdoor Advertising display option, and the sizes include,- 32", 43", 50", 55", 65", 75", 86", 98"
Customized Floor Stand Landscape, Horizontal outdoor display with wheels stand
Customized Clarification:
a series of dimensions for various sizes, when the shape and configurations of the free standing digital signage are different, it will be a little change measurements.
The change / customized include the following
1. Out-looking & Color, include based stand
2. Configurations different: card reader, android LAN (default equipment), PC built-in
3. Touch Screen built-in, Infrared or Capacitive multi touch
4. Built-in Camera
5. Built-in printer, card reader ... etc.
Above picture is 98" vertical digital totem display we produced.
Vertical / Horizontal / landscape option.
Welcome to customize the outdoor digital signage, built-in PC, android OS, air-conditioner, cooling system, camera .. option. and usually the touch screen will be Nano foil touch, 10points.The Technical Parameter for Outdoor Advertising Display Kiosk
Remark: just for reference, the actual parameters will be some difference per different components
Size | | | 43" | | | | |
Screen Panel | | | D-LED screen panel *2, double sides | | | | |
| | | 16:9 | | | | |
Resolution | | | 1920*1080 HD | | | | |
Brightness | | | 1500 cd/m² | | | | |
Contrast Ratio | | | 2000:1 | | | | |
Viewing Angle | | | 178 ° horizontal / 178 ° vertical | | | | |
Touch Screen | | | Nano Touch 10point *2 | | | | |
Built-in Camera | | | 2 million pixels, wide-angle distortion free *2 | | | | |
Built-in PC | | | Intel I3, 4GB Memory, 128GB SSD, WIFI *1 | | | | |
Power on/off | | | Industrial levels of the switching power supply | | | | |
Spearker | | | 2* 10W Waterproof speaker | | | | |
Anti-thunder | | | three graded for Alternating Current; and protect the signal of LAN cable | | | | |
Leakage protection | | | 30MA current | | | | |
Timer | | | time on/off per day / week | | | | |
Brightness Control | | | Automatic light sensor system | | | | |
Temperature Control System | | | Air-cooling and heating system | | | | |
Operating Temperature | | | -30°C to +50°C | | | | |
Operating Humidity | | | 5% to 100% | | | | |
| | | AC 110 -240V | | | | |
Max Consumption | | | 850W | | | | |
Waterproof Enclosure | | | 1.5mm galvanized steel, the surface with special powder sprayed. Lifetime: 7years; Open door with waterproof construciton &
outdoor rubber closure. | | | | |
Protection Grade | | | IP65 | | | | |
Glass protection | | | 6mm sided laminated glass, anti-glare with AR coating, high transmittance, low reflection, anti-explosion; anti 99.99% UV rays,
anti 52% solar heat, transmittance: > 97% , reflectance : < 3 %; | | | | |
Products Size (W*H*D) | | | to be advised | | | | |
Gross weight | | | to be advised | | | | |
Installation | | | Floor standing or customized | | | | |
Protection Glass | | | 6mm AR safe glass | | | | |
Remark: Size range of outdoor floor standing digital signage display : 32", 43", 50", 55", 65", 75". 86", 98" Any we can talk in case by case
Above are some pictures of outdoor display kiosk which we produced, we can design per clients requirements.
