New interactive whiteboards for business optical company for teaching

Company Advantages
1. ITATOUCH interactive whiteboards for business is developed according to the basic law of the construction of machines, including the drive system, operate and control system, and the supporting device working principle.
2. This product has electromagnetic compatibility. It has passed EMC testing for verifying its ability to withstanding EM energy which may occur within its operational environment.
3. This product has electromagnetic compatibility. Techniques and technologies for reducing disturbance and enhancing immunity are cleverly used in its manufacturing.
4. The product can be used to break up a single large area into separate sections, bringing order to what was once a confusing environment.

Movable Wheels Ir Led Touch Screen Panel Display Smart Board China Interactive Whiteboard

Product Details



                                            * Key Features for Interactive Flat Panel









                                           *  Detailed Picture for Interactive Touch Screen







Front Frame









                                                      *  Application for LED Interactive Whiteboard



                     Specification Of Interactive Touch Display



Specification
Panel
Sizes	54.64inch	64.53inch	74.52inch
Screen Panel Type	D-LED	D-LED	D-LED
Resolution	3840*2160	3840*2160	3840*2160
Brightness (type)	350 cd/㎡	400 cd/㎡	400 cd/㎡
Contrast	4000:1	4000:1	1200:1
Display Area	1209.6*680.4 mm	1428.5*803.5 mm	1649.66*927.94mm
Pixel (mm)(H/V)	0.21 x 0.63	0.372x 0.372	0.429 x 0.429
Display Rate	16:9	16:9	16:9
Reviewing Angle	178°	178°	178°
Colorful	10bit,10.7B	10bit,10.7B	10bit,10.7B
Response time	8ms	6ms	6ms
Lifetime	Above 50,000h	Above 50,000h	Above 50,000h
Touch Glass	AG	AG	AG
Sound System
Speaker	2*15W	2*15W	2*15W
Video type	PAL、NTSC、SECAM	PAL、NTSC、SECAM	PAL、NTSC、SECAM
Sound type	D/K、 B/G、 I、M	D/K、 B/G、 I、M	D/K、 B/G、 I、M
Android System
Android OS	Andriod 6.0 OS	Andriod 6.0 OS	Andriod 6.0 OS
Android CPU	CPU：Cortex A53*4 1.5GHz  GPU：ARM Mali-T720
Flash Nandi  EMMC	8G	8G	8G
RAM  DDR3	2G	2G	2G
Input Resolution	1920*1080/60HZ, 3840*2160/60HZ
Front Frame	1* HDMI, 2*USB2.0,  1* TOUCH-USB
Input	2*HDMI, 1*VGA,  1*YPBPR,  1*AV ,  2*USB2.0, 1*TOUCH-USB, 1*RS232, 1*SD (MAX support 128GB) , 1*RJ45, 1*WIFI (2.4G ) , 1*OPS PC SLOT 80PIN
Output	1*SPDIF,, 1*Earphone, 1*AV
Front Button	POWER,  MENU,  VOL- , VOL+, ECO,  ENTER, HOME
Touch Technology
Touch Points	Infrared 10-20 touch points, support 2, 6, 10, 20-touching for windows
Touch Method	Finger or Pens, any objects
Calibration Technology	Infrared magnetical sensor
Accuration	<2mm	<2mm	<2mm
Resolution	4096*4096/16384*16384/32768*32768
Response time -1st touch	<15ms	<15ms	<15ms
Continous touching	<8ms	<8ms	<8ms
Light Sensor	>220dot/second	>220dot/second	>220dot/second
Touch interface	USB	USB	USB
Support OS	Support WINDOWS /LINUX /MAC  /Android
Touch objects	≥Φ3mm	≥Φ3mm	≥Φ3mm
Touch times	above 6000millions times at same point
Software under Andriod OS
Whiteboard App	Yes	Yes	Yes
Mirror Screens	Option	Option	Option
Google App	Compatiable	Compatiable	Compatiable
Power Supply
Power	AC(100-240)V～50/60HZ
Rated current	1.5A	2.5A	3A
Environments
Temperature	Working Temperature: 0°C to 40°C ;   Storage Temperature :-20°C to 55°C;
Humidity	20%-80% RH at 40°C, non-condensing
Others
The shell	Black bezel/ Aluminum alloy frame with Oxidation drawing treatment/metal shell of the backside
Accessories	Magnetic Touch Pen x2	Magnetic Touch Pen x2	Magnetic Touch Pen x2
	HDMI cable (1.5M) x1	HDMI cable (1.5M) x1	HDMI cable (1.5M) x1
	USB cable (1.5M) x 1	USB touch cable (1.5M) x 1	USB touch cable (1.5M) x 1
	Power cable（1.8M) x 1	Power cable（1.8M) x 1	Power cable（1.8M) x 1
	Remote control  x 1	Remote control  x 1	Remote control  x 1
Package Dimension	1385*195*870mm	1630*210*1060mm	1890*250*1190mm
Net Weight	39Kg±1Kg	45Kg±1Kg	79Kg±1Kg
Gross Weight	49.5Kg±1.5Kg	62.47Kg±1.5Kg	85Kg±1.5Kg

Other sizes 86", 98" Interactive Panel option

OEM | ODM supporting!





Brief Functions Description for ITA TOUCH Whiteboard Software



ITA Touch Whiteboard Software has powerful features, and very easy use for user.it can hide all display items, just show
whiteboard floated icon, adjust the main MENU direction, and free change short-cut list to display on right side, or left side,
hide source ... etc.
- It is FREE Whiteboard Software for our clients
- Normal features all offered, such as zoom, rotated, annotation, edit, play video, images, all course of tools, background

- The key features are to
1. Directly drag the images, or content words from website, it is quite convenient for teacher/conference... etc.
2. It has two-screens, and which can transport the content to another screens.
3. Lab tools and all kinds of course pictures.
- Support multi touchpoints.
- Multi-languages: English, Spanish, Polish, Russian, Arabic, Germany, France ... etc.
- OEM supporting - provide the whiteboard software with client LOGO, or add some features option

Optional Product

 These interactive devices could be equipped with Interactive Touch Display, customer can select them per the actual requirements. Welcome to the inquiry!



Please do not hesitate to contact with us if there is any query!





Packing  for Interactive Touch Panel



Please do not hestate to talk with us if there is any query!

                                                                          Why Choose Us

Company Features
1. As time changes, ITATOUCH has been always doing its utmost to provide trending interactive whiteboards for business.
2. Our interactive digital whiteboard are designed to target specific interactive whiteboard device .
3. Shenzhen ITA Touch Technology Co., LTD will be very honored if we have the opportunity to work with you. Inquire! The mission of ITATOUCH motivates each staff to work hard. Inquire! Shenzhen ITA Touch Technology Co., LTD has been improving our ability to serve clients. Inquire! People-oriented is a corporate culture for ITATOUCH to advocate. Inquire!
