Optical finger/ any objects touch, 2points (2 cameras), or 10points (4cameras), write smoothly, response fast
A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years
The interactive white board is widely used for educcation / school / classroom, conference, office meetitng, military, govemrent, hotel ... etc. and gets highly appreciated from wide world market.
ITATOUCH interactive whiteboard adopts 9th generation infrared multi touch technology, high-density infrared light tube integrated PCB, which offer the quality and multi touch points (10 ~32points) is under control and management to be easily maintained and used.
With the designed appearance and conscientious service, ITATOUCH interactive whiteboard has been widely appreciated from wide world markets.
Optical finger/ any objects touch, 2points (2 cameras), or 10points (4cameras), write smoothly, response fast
The whiteboard software with mutli-features, compatible with WIN /Linux / Android OS
Gesture recognize to write, eraser, zoom in/out, block .. record,/play video, edit/annotate
free whiteboard software with multi lanuages also, inlcude English, Spanish, French, Russia, Arabic
On both sides there are 22pcs shortcuts, which is very convenient and easy for user
Alunium frame with painting classical grey, fashion corner protected. hotsale style
ITATOUCH Interactive Optical Whiteboard with two kinds of solutions, 2 cameras & 4 cameras, which is separately 2touch points & 10points, Clients could select the interactive boards per the actual requirements. Three years warranty offered by ITATOUCH.
The package of ITATOUCH interactive boards include whiteboard software, which is a powerful interactive tool, ideally for education and business applications. The whiteboard can fulfill functions including handwriting, erase, add /edit pages, insert objects, record...etc., which will bring the teaching, learning and meeting with a vivid and interactive presentation.
- 18pieces Shortcut Keys on both sides
- 2points ~10points finger touch
- Aluminum frame with baked painting in black
- ABS Corner with painted color
- Free Whiteboard software
The board materials will be constructed by three parts: Surface, Wick and Back, see below picture.,
Customer could choose the materials of this interactive whiteboard,
Surface Material:
Option A: Cold rolled steel surface, anti-damage, Nano surface.
Option B: Cold rolled steel surface, anti-damage, ceramic surface, hardness 7H. Dry-Ease, support marker pen.
Back: Galvanized Steel Sheel
Size | Ratio | Projection (mm) | Active (mm) | Total Area (mm) | |||
L | W | L | W | L | W | ||
85” | 4:3 | 1592 | 1195 | 1697 | 1195 | 1754 | 1289 |
Size | Ratio | Projection (mm) | Active (mm) | Total Area (mm) | |||
L | W | L | W | L | W | ||
85” | 4:3 | 1592 | 1195 | 1697 | 1202 | 1754 | 1259 |
91.9” | 16:9 | 1184 | 1060 | 1989 | 1067 | 2046 | 1124 |
Input Method | Finger or any other opaque object |
Transmittance | 100% without glass (or board panel) |
Touch Durability | Unlimited |
Touch Object Diameter | ≥10mm |
Touch Activation Force | No pressure required |
USB reported Resolution | 32768*32768 |
Interface Type | USB2.0 (Full Speed) |
Plug and Play | Supported |
HID | Supported |
Power Supply | Powered by USB |
Power Requirements | DC5V±5% @500mA |
Power Consumption | 5VAverage power consumption<2.5W,@5V |
Operating Temperature | 0℃~55℃ |
Storage Temperature | -25℃~75℃ |
Operating Humidity | 10% to 90% RH, non-condensing |
Storage Humidity | 10% to 90% RH, non-condensing |
Drift | No drift in operating temperature range |
ESD | Per EN 61000-4-2: Level 4, contact discharge 6KV, air discharge 8KV |
Mounting Flatness | ±2.5 mm |
The package will be settled by wooden case or pallet to ensure the shipment safety, ITATOUCH will keep communicate with our clients to arrange all, include Air (by express or airport) and Ocean shipment.
The Accessories Box:
1* Wall Mounted
1* Pointer
1* Eraser
1* Whiteboard Software CD
Small box of the accessories package to be packed into the whiteboard carton
The Interactive Boards will be packed by double cartons, and fold the foam to ensure safety.
Package with stripe belt, and settle the wooden pallet if needs . (Container Loading)
Q: Which accessories would be included for the package of this interactive boards?
R: the package accessories as below,
1* Wall Mounted
1* Pointer
1* Eraser
1* Whiteboard Software CD
Q: What is the Lead-time?
R: Leadtime: within 15 days for 20' GP/40HQ Contatiner Qty
Q: How long time is for the warranty?
R: Three years .
Q: How to order it?
R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.
