A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years

poster portable table ITATOUCH Brand video wall flat panel display factory 1
poster portable table ITATOUCH Brand video wall flat panel display factory 2
poster portable table ITATOUCH Brand video wall flat panel display factory 3
poster portable table ITATOUCH Brand video wall flat panel display factory 4
poster portable table ITATOUCH Brand video wall flat panel display factory 5
poster portable table ITATOUCH Brand video wall flat panel display factory 1
poster portable table ITATOUCH Brand video wall flat panel display factory 2
poster portable table ITATOUCH Brand video wall flat panel display factory 3
poster portable table ITATOUCH Brand video wall flat panel display factory 4
poster portable table ITATOUCH Brand video wall flat panel display factory 5

poster portable table ITATOUCH Brand video wall flat panel display factory

Model#:
HT-22D
Size Range:
18.5", 21.5", 24", 27"
Touch Tech:
Projected Capacitive 10points
Resolution:
1920x1080P
OS:
Android / Windows
Interfaces:
USB, HDMI, VGA,
Computer :
Built-in, Intel I3 /I5 /I7, 4GB/8GB
Supply Ability:
5000piece per month
Min. Order:
1piece
Payment:
T/T, Western Union, PayPal, Alipay, L/C
Shipping:
Express / Air / Sea per the requirements (Transparent and fair price, online tracking)
Port:
Shenzhen, China
Inquiry
Company Advantages
1. Ita Touch: Offer the Best Intelligent Products. As one of the unique feature, video wall flat panel display successfully makes video wall with touch screen more popular among customers. Ita Touch: Offer the Best Intelligent Products
2. Shenzhen ITA Touch Technology Co., LTD, well-known for its superior quality, will provide first-class service. Ita Touch exceeds your expectation
3. Shenzhen ITA Touch Technology Co., LTD have specialized in high tolerance touch screen video wall machining for free standing interactive whiteboard years. Interactive products, Efficient communication.
4. To add, to cater maximum level of client satisfaction, we offer modified solutions for these electrical display stand to our patrons. Ita Touch-Start your Intelligent Life
5. On account of multiple advanced technology, smart interactive whiteboard now stands out in this industry.



PACP Multi Touch Screen Display

Camera, Card Reader, Android/ PC


ITATOUCH produces the small size capacitive touch screen display for any commercial use, projected capacitive technology, built-in Camera, Card Reader,etc. customized supporting. User could select the device por actual use.

ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture
 Card Reader Built-in
This touch screen with card reader & carmera
And
ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-1
Normal Appanrance
The standard touch screen, built-in carmera option
Products Details


Capacitive Technology

ITATOUCH Interactive Flat Panels integrated in projected capacitive touch screen, full high-definition 1080P display, android OS / Computer, and the client could choose other configurations also, such as: built-in camera, carder reader … etc.

ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-2
PCAP Touch Screen

Projected capacitive touch screen technology, 10 points finger touch, intelligence gesture, write smoothly

ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-3
Built-in PC / Android OS

Android OS, 2GB RAM, 16GB flash Nandi. or PC Intel I3 /I5 /I7 4GB/8GB option

ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-4
2K 1080P FHD

FHD 1080P screen panel from LG, SAMSUNG, AUO .. , quality A+, perfect out-looking

ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-5
Customized Supporting

Supporting cusotmized, built-in camera, card reader,etc. hotsale stylish

ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-6

The standard android board is high-performance RK3368, quad-core CPU 1.8GHz, 2GB RAM, built-in PC Intel J1900, I3, I5, I7, 4GB/8GB option.
Since the high-integrated all in one feature, it would be widely applied classroom, school, store, supermarket, station, airport, office, etc for information display, checking for any smart use, which strongly improves the working effectiveness

ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-7

- FHD 1080P display
- Projected capacitive touch screen, 10points
- Android OS or Windows OS, WIFI built-in
- Built-in Camera, card reader option
- Two kinds of the appearance for the different applications
- Full sizes: 18.5”, 21.5”, 27”



SPECIFICATION



Screen PanelSize18.5"21.5" 27"
Sceen panelLCD LED backlight
View Area409.8*230.4mm476.64x268.11mm597.6*36.15mm
Resolutions1366*7681920*10801920*1080
Contrast 600:13000:13000:1
Brightness350cd/㎡250cd/㎡300 cd/㎡
Response time8ms6.5ms12ms
Viewing Angle100°(H) / 75°(V)170°(H) / 160°(V)178°(H) / 178°(V)
Lifetime30,000 hrs (min.)30,000 hrs (min.)30,000 hrs (min.)
Speaker 2W*2,8Ω2W*2,8Ω10W*2
Android  (Option)Mainboard RK3368 A83T 8cores 1.8GHz    CPU, Memory 2G, 64bit,  Flash Nand    8G,  WIFI, Android 5.1 OS
Computer    (Option)Mainboard H61 / H81 Chipset
CPUInteCorei7/i5/i3/G2030/Celeron    CPU 1150-pin
RAMDDR3 1333Mhz  4G/8
StorageSATA500G;SSD60G/120G
WiFiyes, with antenna
OS Compatiable with WINDOWS    7/8, 10.. Etc
Interfaces I/O  USB*2,    RJ45*1; SD*1; Microphone *1
Touch (Option)TechnologyCapacitive 10point touch.    Free driver, finger touch; 95% touch area,     accuracy ± 2mm
Camera (Option)Module Size55.2mm × 19mm × 24.5 mm;    2~5 millon piexls, USB2.0 interface
Object distance 15CM-80CM
Card Reader (Option)agreement:    ISO14443A/ISO14443B/ISO15693 , Frenqucy: 13.56MHZ, Communication Interface:    TTL;
OthersButtonPower on/off, Light lamp
Power    SupplyPower AC100 V ~ 240 V, 50-60 Hz
Consumption≤40W≤60W≤60W
Standby≤1W≤1W≤1W
EnvirnormentTemperatureWorking: -20℃~60℃,    Storage:-40℃~85℃
HumidityWorking: 10%~90%RH,  Storage: 10%~95%RH
Max working time 18 hours /day
AppranceCaseAluminum alloy frame with    paint sliver
InstallationWall mounted
PackageProducts467.1x299.1x52.6532.72x336.72x51.6mm655.1x405.1x53.1mm
Packages
WeightN/W 5.5KGN/W 6.5KGN/W 7.8KG
AccessoriesPower cable, wall mounts,    user manal

Remark:  just for reference, the actual parameters will be some deviations per different components.



Dimensions



18.5inch’s

++
ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-8
ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-9

21.5inch’s

++

27inch’s

++
ITATOUCH-Best Capacitive Touch Screen 215 Android Tablet Monitor Manufacture-10



Package


The package will be settled by wooden case or pallet to ensure the shipment safety,. ITATOUCH will keep communicate with our clients to arrange all, include Air (by express or airport) and Ocean shipment.




Container loading - the package with pallet and plastic flim to anit-damaged and waterproof




The workers are setting the safety strips to avoid shocking damaged during shipment.



Air shipment for small order quantity - settle wooden case or pallet with stripe to ensure safety.


FAQ

Q: This andriod touch scree monitor could be customized?

 R: Yes, offer customizied service, OEM welcome. Please give us what you like to, such as camera, card reader, android board ... etc .





Q: What is the MOQ for customized.

 R: MOQ: 10pcs.





Q: How Long Leadtime for customized units.

 R: It would be around 15~25pcs, which is based on the status of the changing. if no constructure change, then around 10days. it could be talk in case by case.


.

Q: How long time is for the warranty?

 R:  Usually it is one year.  Certainly, three years also except the sceen panel (since the factory of screen panel just offered one year). we could talk in case by case.




Q: How to order it?

R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.




Q: Which accessories would be included for the package of this interactive panels?

R:  the package accessories as below,

1* Remote Control
1* USB Cable
1* Power Cable  (the international standard, such as: EU, UK, US ..  per usser location)
1* Wall Mounted
