IR 9th generation technology, finger & any objects touch, support 10 users writing, response fast , smoothly
A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years
Popular out-looking with multi functions and features, which are mainly used for education, school, classroom, conference, military … etc
Full touch to switch the channels for interactive Flat panel
Just touching the bottom of the touch screen panel, you will see a list menu , include adjust the brightness, Voice, System, cutting-screen, all channels, writing and edit … etc.
Interactive Touch Panel usually is applied in school classroom for interactive teaching/learning, office/goverment meeting conference, hotel/ airport/supermarket for instruction, advertising display, booking ... etc.
ITATOUCH Interactive Touch Panels adopts 9th generation infrared multi touch technology, high-density infrared light tube integrated PCB, which guarantee the touch sensor is accurate and smooth, offer multiple users (10points touch) good and pleased feeling.
ITATOUCH NZ Series Interactive Flat Panel with built-in android OS and OPS PC are attachable, users do not need the projector again to create an interactive learning / teaching / meeting the environment, which is so easy and convenient.
IR 9th generation technology, finger & any objects touch, support 10 users writing, response fast , smoothly
LED backlight, LG /Samsung / AUO screen panel , 1920*1080p or 3840*2160 resolutions
Android 5.0 OS, 4cores CPU, 1GB/2GB RAM, WIFI. option OPS PC Intel I3 / I5 / I7, 4GB/8GB
Intelligence gesture, touch switching all, one key power on/off , auto-sensor, eye-protection, kids lock, engery saving ...
AG glass option for interactive panel, real synthetic anti-glare technology for all lifetime
Android OS with interactive transferring software, support multi screens, divided screens, gesture eraser ...
On the middle of front bottom with interfaces and press button ( inside the door )
Infrared Multi Touch Screen
Infrared 9th generation technology, finger and any objects touch screen, 4mm tempered glass, high transmittance
Fast response, write/annotate smoothly for teaching and demo presentation.
Support over 10 people write on the screen at the same time, people will enjoy the using experience.
Anti-light interference, anti-shadow, adapt to a variety of environments
Easy maintenance and replacement – equipped with self-checking software in case any problem happens.
Android & Windows OS
Android mainboard built-in, android 5.0 /6.0 OS , quad-core CPU, 1GB/2GB DDR3/DDR4 RAM, it also could smoothly sue the touch screen even if there is no computer connecting, including access to the internet, edit, annotate, upload /save files … etc which offer non-worried application environments.
Android OS with multi-languages, include English, Spanish, Russian, Polish, Germany, Turkey, Arabic …
OPS SLOTs for OPS PC attachable
User could select the OPS PC configuration, including Intel I3 / I5 / I7 CPU, 4GB/8GB DDR3/DDR4 RAM, 120G/256G SSD or 500GB / 1TB HDD, CJPU chipset: H61 /H81 /H110.
2K / 4K Screen Panel
The screen panel will be LCD LED backlight, 2K /1080P or 4K / 2160P display, which offers the presentation with real and vivid images and words, giving a deep impressive teaching/conference.
Intelligence gesture recognize
Based on your gesture,you can control the touch display, include J Zoom in / out, Rotate, Erase, Multi Tasks Witching, Write …for easy teaching and presentation.
Full touch to switch the channels
Touch the bottom to pull up, there well be the menu channels, including TV System, Android, OPS PC, HDMI 1/2/3, Sources, Display, then user could select the channels accordingly, including adjust the screen parameters.
Anti-Glared Glass
If user need the anti-reflective device, then the tempered glass will be handled with special technology, so please bring out when you order.
Round Corner, anti-scratch screen
Module design with LED backlight screen panel, the device is thin and narrow, include the touch panel – tempered glass.
The stylish appearance with metal drawing, die-modular polishing,
Front buttons & Interfaces
On front bottom with the buttons – Menu, Sources, Vol +, Vol-, Interfaces: USB-Touch, USB-TV, HDMI
Screen panel | ||||
Panel size | 55inch | 65inch | 75inch | 86inch |
Screen panel | TFT screen panel, LED backlight | |||
Display (mm)(H/V) | 1209.6 x 680.4 | 1428.48 x803.52 | 1650.24 x928.26 | 1872 x1053 |
Display Rate | 16:09 | 16:09 | 16:09 | 16:09 |
Max resolution | 1920x1080 | 3840x2160 | 3840x2160 | 3840x2160 |
Display color | 16.7M | 1.07B | 1.07G | 16.7M |
Pixel (mm)(H/V) | 0.21×0.63 | 0.372*0.372 | 0.143(H) mm x 0.430 | 0.4875 x 0.4875 |
Brightness (nits) | 300cd | 400cd/m² | 400cd/m² | 350cd/m² |
Contrast | 1200:1 | 1200:1 | 1100:1 | 1200:1 |
Visual angle | ±178° | ±178° | ±178° | ±176° |
Response time | 8ms | 6ms | 6ms | 8ms |
Speaker | MAX power: 15W*2 | |||
Mainboard | ||||
Android Mainboard (Option) | Android mainboard, Clocked CPU 1.4GHz, Memory 1GHz, Flash Nand 4GB, Android 5.0 OS ; | |||
Input: Mini-YPBPR*1, Mini-AV*1, PC-AUDIO*1, VGA*1, TV-USB2.0*2, UHD1.4*1 UHD2.0*1 (only for 4K display), HDMI built-in *1; RS232*1; RJ45*1, SD Card Reader for android *1 | ||||
Output: Earphone*1; AV(mini)*1; SPIDF*1; Touch USB *2 | ||||
Front Interfaces: HDMI*1; VGA*1; PC-Audio*; ALL-USB*2; Touch-USB*1; Mini Microphone*1 | ||||
Front Buttons: PC Power; TV Power; MENU; Source; VOL+, VOL-, Energy; Power on/off | ||||
Features | 1. One key to power/on offer the screen and device; automatically power off. One-key lock the display; Automatic wake-up and child-lock function | |||
OPS COMPUTER | ||||
CPU | Intel Core i7/i5/i3/Celeron CPU 1150-pin; Integrated HD Graphics; built-in HD audio 6(Realtek ALC661) | |||
Memory | DDR3 1333Mhz 4G/8G option | |||
SSD | 120G SSD (240G SSD or 500G HDD option) | |||
Wi-Fi | Optional, Wi-Fi with Antenna, 802.11 b/g/n | |||
PC Ports | HDMI×1, VGA×1, USB2.0×2, USB3.0×2, RJ45×1, PCAUDIO×1, MIC×1, RS232×1 | |||
Touch Technology | ||||
Multi Touch | Infrared technology,, 10point touch; finger or any objects touch | |||
Glass | Tempered glass, 4mm, Transparency rate>95%; 32768(W) × 32768(D) ; | |||
Resolution | Response speed: 5ms; Typical accuracy<1.5mm;Cursor Speed:180 d/s around; | |||
Features | No drift, drive-free, waterproof, anti-dust; finger/object multi-touch, intelligence gesture recognizes etc | |||
OS | Support Windows 7/ Windows 8 | |||
Whiteboard Software | Option, widely used to education, conference, military etc; multi-functions and multi-languages; compatible with Windows OS | |||
Power supply | ||||
Power supply | AC100~240V 50 /60 HZ; Consumption: Standby <1W | |||
Consumption | ≦200W | ≦250W | ≦300W | ≦500W |
Environments | Working: 0°C to 40°C ;Storage:-20°C to 55°C; Humidity:20%-80% RH at 40°C, non-condensing | |||
Physical Features | ||||
Case | Black color/ Aluminum alloy/ metal case | |||
Dimension | 1291.8*799.1*81.2 | 1511.2*922.7*81.2 | 1733.2*1048.7*81.2 | 1979.4*1197.7*121 |
Mount (mm) | 23.3mm | 23mm | 23.3mm | 8.5mm |
Package (mm) | 1495*925*245 | 1710*1135*245 | 1910*1285* 245 | 2150*1410*295 |
CBM | 0.35 | 0.5 | 0.53 | 0.73 |
N/W & G/W (kg) | 54 & 65kg | 78 & 92kg | 79 & 96kg | 115& 136kg |
20'GP/40'HQ | 90/220pcs | 55/140pcs | 48/125pcs | 37/95pcs |
Accessories | ISO9001,ROHS, CE, FCC | |||
User Guide, Warranty card, Remote Control, USB Cable 3m; Power Cable 1.5m; Touch Pens /2pcs, |
The package will be settled by wooden case or pallet to ensure the shipment safety,. ITATOUCH will keep in touch with our clients to arrange all,processes including Air (by express or airport) and Ocean shipment.
Q: Which accessories would be included for the package of this interactive touch panel?
R: the package accessories as below,
Q: What is the Lead-time?
R: Leadtime: within 10days for 1~10pcs. around 10~20days for 20~100pcs.
Q: How long time is for the warranty?
R: Usually it is one year. Certainly, three years also except the sceen panel (since the factory of screen panel just offered one year). we could talk case by case.
Q: How to order it?
R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.
Q: Does ITATOUCH provide the OS for the interactive touch screen with OPS PC ?
R: Normally offer the finish device only, certainly we could help to install a tral version (WIN 7 / WIN 10) if needed, since we are the hardware interactive touch screen manufacturer.
Q: Is there extra whiteboard software for this interactive panel?
R: Yes, ITATOUCH could offer the whiteboard software if needed, or User could download it from website.
