school teaching smart portable board interactive whiteboard for classroom 3 buyers
School teaching smart portable board interactive whiteboard for classroom
| Model# | HT-55D S Series | HT-65D S Series | HT-75D S Series | HT-86D S Series | HT-98D S Series |
| Screen Panel | |||||
| Sizes | 55inch | 65inch | 75inch | 85/86inch | 98” |
| Screen Panel Type | D-LED | D-LED | D-LED | D-LED | LG D-LED |
| Resolution | 3840*2160 | 3840*2160 | 3840*2160 | 3840 x 2160 | 3840 x 2160 |
| Brightness (type) | 320 cd/m² | 350 cd/m² | 400 cd/m² | 350 cd/m² nits (typ.) | 500cd/m²(typ.) |
| Contrast | 4000:1 | 4000:1 | 1200:1 | 1200:1 (typ.) | 1300;1 (typ.) |
| Display Area | 1209.6*680.4 mm | 1428.5*803.5 mm | 1649.66*927.94mm | 1860.48 ×1046.52 | 2158.848*1214.352 |
| Pixel (mm)(H/V) | 0.21 x 0.63 | 0.372x 0.372 | 0.429 x 0.429 | 0.4935 x 0.4935 | 0.5622*0.5622mm |
| Display Rate | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 |
| Reviewing Angle | 178° | 178° | 178° | 178° | 178 °(H) / 178 °(V) |
| Colorful | 10bit,10.7B | 10bit,10.7B | 10bit,10.7B | 1.07B (10bit) | 1.07B (10bit) (V) |
| Response time | 8ms | 6ms | 6ms | 8ms | 5ms |
| Lifetime | Above 50,000h | Above 50,000h | Above 50,000h | 50,000 hrs (min.) | 30,000 hrs (min.) |
| Touch Glass | 4mm tempered glass / Anti-glared glass | ||||
| Sound & Network & Light System | |||||
| Speaker | 2*10W | 2*15W | 2*15W | 2*15W | 2*15W |
| Video Input/Output | HDMI: Max. 3840X2160@60Hz, HDMI 1.4/2.0,HDCP 1.4/2.2 | ||||
| Audio | PC/CVBS/Component Audio: Audio L/R input; Earphone/CVBS Output | ||||
| Network | Network: 10/100M auto-identification and DHCP | ||||
| WIFI | IEEE 802.11a/b/g/n/ac 2.4GHz/5GHz 2T2R WIFI | ||||
| Bluetooth | BT5.0 | ||||
| Android System | |||||
| Android OS | Andriod 11.0 OS | Andriod 11.0 OS | Andriod 11.0 OS | Andriod 11.0 OS | Andriod 11.0 OS |
| Android CPU | 64-bit Quad-core ARM Cortex-A55 CPU, Max.1.9GHz; ARM Mali-G52 MP2 (2EE) GPU, 900MHz | ||||
| Flash Nandi EMMC | 32GB / 128GB | 32GB / 128GB | 32GB / 128GB | 32GB / 128GB | 32GB / 128GB |
| RAM DDR3 | 4GB / 8GB | 4GB / 8GB | 4GB / 8GB | 4GB / 8GB | 4GB / 8GB |
| Input Resolution | 1920*1080/30HZ, 3840*2160/60HZ | ||||
| Front Frame | 2*USB / 1* HDMI, 3*USB2.0/3.0, 1* TOUCH-USB , 1*Type-C | ||||
| Input | 1x COAX, 1xRS232, 1xMINI AV, 1xEARPHONE, 1xMIC IN, 1xRJ45 IN, 2x HDMI, 1x Android USB2.0,1x Public USB3.0, 1x TF CARD, 1*WIFI (2.4G/5.0G ) , 1*OPS PC SLOT 80PIN; | ||||
| Output | 1xMINI AV OUT, 1x RJ45 OUT, 1x TOUCH OUT, | ||||
| Front Button | POWER / 7 BUTTONS OPTON | ||||
| Software under Andriod OS | |||||
| Whiteboard App | 4KUI, edit, writing in two color with small/big pen nibs, eraser, scann share … etc. | ||||
| Application Tools | Annotation, Vote, Screenshot, Record, Timer, Child Lock, Energy, Camera … etc | ||||
| Mirror Screens /E-Share | Option | Option | Option | Option | Option |
| Google App | Compatiable | Compatiable | Compatiable | Compatiable | Compatiable |
| Touch Technology | |||||
| Touch Points | Infrared 10-20 touch points, at most support 4 pen writing at the same tim | ||||
| Touch Method | Infrared magnetical sensor, Finger or Pens, any objects | ||||
| Touch Accuracy | 1mm +/- | 1mm +/- | 1mm +/- | 1mm +/- | 1mm +/- |
| Resolution | 4096*4096/16384*16384/32768*32768 | ||||
| Response time -single point | <=7ms | <=7ms | <=7ms | <=7ms | <=7ms |
| Touch refersh rate | >=140fps | >=140fps | >=140fps | >=140fps | >=140fps |
| Touch interface | USB | USB | USB | USB | USB |
| Support OS | Support WINDOWS /LINUX /MAC /Android | ||||
| Touch objects | ≥Φ2.5mm | ≥Φ2.5mm | ≥Φ2.5mm | ≥Φ2.5mm | ≥Φ2.5mm |
| Touch times | above 6000millions times at same point | ||||
| Power Supply | |||||
| Power | AC(100-240)V~50/60HZ | ||||
| Power Consumpation | 130W; Standby<0.5W | 170W; Standby<0.5W | 230W; Standby<0.5W | 325W; Standby<0.5W | 505W; Standby<0.5W |
| Environments | |||||
| Temperature | Working Temperature: 0°C to 40°C ; Storage Temperature :-20°C to 55°C; | ||||
| Humidity | 20%-80% RH at 40°C, non-condensing | ||||
| Others | |||||
| The shell | Black/Sliver bezel/ Aluminum alloy frame with Oxiation drawing treatment / metal shell of backside | ||||
| Accessories | Touch Pen x2 | Touch Pen x2 | Touch Pen x2 | Touch Pen x2 | Touch Pen x2 |
| HDMI cable x1 | HDMI cable x1 | HDMI cable x1 | HDMI cable x1 | HDMI cable x1 | |
| USB A-B cable x 1 | USB A-B cable x 1 | USB A-B cable x 1 | USB A-B cable x 1 | USB A-B cable x 1 | |
| Power cable x 1 | Power cable x 1 | Power cable x 1 | Power cable x 1 | Power cable x 1 | |
| Remote control x 1 | Remote control x 1 | Remote control x 1 | Remote control x 1 | Remote control x 1 | |
| Product Diension | 1257.6 *743.6*84.7mm | 1482.7 *879.5*91.8mm | 1704.6*1006.9*91.8mm | 1950.8*1145.5*91.8mm | 2215.2*1300.1*95.7mm |
| Package Dimension | 1370*880*180mm | 1610*1010*200mm | 1790*220*1090mm | 2080*1290*250mm | 2350*1565*310mm |
| Net Weight | 27Kg±1Kg | 40Kg±1Kg | 56Kg±1Kg | 72Kg±1Kg | 95Kg±1Kg |
| Gross Weight | 32Kg±1.5Kg | 48Kg±1.5Kg | 70Kg±1.5Kg | 83Kg±1.5Kg | 115Kg±1.5Kg |
| Quality Compliance | CE, FCC, ROHS, ISO | ||||
ITA TOUCH Smart Whiteboard Software
ITA Touch Whiteboard Software has powerful features, and quite easily annotate on the screen for all files for user. and can hidden whiteboard floated icon, adjust the main MENU direction, and free change short-cut list to display on right side, or left side, hide source ... etc.
- The Smart Whiteboard Software is FREE OFFER for our clients
- Normal features all offered, such as zoom, rotated, annotation, edit, play video, images, all course of tools, background
- The key features are to
1. Directly drag the images, or content words from website, it is quite convenient for teacher/conference... etc.
2. It has two-screens, and which can transport the content to another screens.
3. Lab tools and all kinds of course pictures.
- Support multi touch points.
- Multi-languages : English, Spanish, Polish, Russian, Arabic, Germany, France ... etc.
- OEM supporting - provide the whiteboard software with client LOGO, or add some features option
Packing Details
ITA TOUCH manufacturer has always implemented strict quality inspection management before packing, including 24~48hours aging test, QA teams check all functions and requirements one by one according to the production order ... etc.
1. Small Pieces
ITATOUCH will settle the wooden case / pallets to ensure the shipment safety by Air /Express.
2. Container
Usually will settle the wooden pallet to easily unload for customers.
The following packing pictures of Interactive Touch Monitor / Digital Display / Interactive Whiteboard / Smartboards for your reference.
Shipment Arrangement
ITA Touch Factory provide NON-WORRY Shipment Service, including the provision of the transport advice, inquire about the shipping costs with the fregith agent, and help to arrange the delivery of our products interactive touch screen display /smart board / interactive flat panel / digital signage display /graphic monitor ... etc.
And DROP SHIPPING SUPPORT for GRAPHIC MONITOR, MINI PC, ALL IN ONE DISPLAY, HOLOGRAM FAN ... etc some small products.
Delivery Leadtime
EXPRESS SHIPMENT: 7~15 DAYS
AIR SHIPMENT: 7~15 DAYS
SEA SHIPMENT: 30~45DAYS
Why Choose Us
1). Alibaba Verified supplier by SGS Certification.
2). Offer patiently & various services - Brand, OEM | ODM | CUSTOMIZED.
3). Small MOQ 1pcs, Direct Factory Prices.
4). Quality complies with CE, FCC, ROHS, ISO certificates.
5). Our products and service have been gotten " Good | Very Good " reviews by above 99% of clients from more than 30 countries and areas.
ITATOUCH PROFILE
Established in Oct 2016, SHENZHEN ITA TOUCH TECHNOLOGY CO., LTD focuses on high-tech interactive products and the development of Interactive Touch Screen Flat Panels, Smart Whiteboards, Holographic Fans, Digital Signage Displays, Tablet Graphic Monitor .. etc. By establishing a scientific management system for production, sales, technical support, and services.
ITATOUCH Factory products have been granted CE, FCC, ROHS, and ISO certificates and are HIGHLY appreciated by customers in more than 30 countries
