Hardware Spec | ||
Lens | Output Pixels | 8 millions, the clarity of the level >= 1200mm lines |
Rotation | 230 ° (H/V) | |
Picture | Zoom | 220x times ; optical zoom: 22x; Digital zoom: 10x |
Special features | positive and negative pictures, freeze, rotate, mirror, text image switching, brightness adjustment, etc .; auto focus, auto white balance, color / black , support split | |
Storage | yes, 32 pictures; unlimted saving to PC | |
Contrast | yes, on one screen | |
RGB i/o | DB15F/L/C *2; output resolution: XGA, SXGA; 1280 * 1024,720P, 1080P. | |
Frame Rate | 720P, 60 frames / sec for the video | |
Interfaces | RS232 | *1 |
Audio i/o | 3.5mm interface *4 (in), *1(out) | |
Video i/o | RCA*1, S-VIDEO*1 | |
Microphone (in) | Standard Microphone socket 6.3mm | |
USB2.0 | *1 | |
LED Light | 2*LED Lights at sides; and with LED backlight on the board. | |
Red & Blue Gain | yes | |
Brightness Adjustment | yes | |
Product Dimensions | 360mm * 331mm * 91mm | |
Net Weight | 2.35KG | |
Power on | Free, when power on the computer, the visualizer will auto on at same time. | |
Software Features: | ||
1. Shoot the document / picture or any objects, and make the demo on the screen. | ||
2, Support some kinds of pens to edit/annotate the file, erase/delete, save, dynamic word insert, free zoom by 1% gradient free zoom to 1000%; | ||
3. the virtual blackboard function: In the demo window can cut any content to edit/annotate | ||
4 Image effects: negative, mirror, black and white, automatic exposure, video freeze, 1: 1, full screen, left and right rotation. | ||
5, image management: support JPG, BMP, PNG, PDF format, support one key shooting in PDF file . | ||
6, Contrast function: support 2,4,9,16 split screen, add picture comparison, dynamic video previewing, support real-time touch zoom, left and right rotation. | ||
7, Record video function : all operations can be record as a video, support MP4, AVI, WMV … etc, support 1080P, 720P and full-screen mode recording. |
ITATOUCH Visualizer support the microscope adapter for education use, this video teach how to install the microscope adapter
Camera: 3.5 / 5 /8 mgpiexls option
Optical zoom: 22x; Digital zoom: 10x
Focus: Auto/ Manual selectable
