A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years
ITATOUCH Visualizer support the microscope adapter for education use, this video teach how to install the microscope adapter
Camera: 3.5 / 5 /8 mgpiexls option
Optical zoom: 22x; Digital zoom: 10x
Focus: Auto/ Manual selectable
Lights:
Arm light: 1.5W LED Lamps *2
Auto white balance
POWER , CAMERA, PC1/PC2, VIDEO, LAMP, FREEZE, AUTO, TELE/WIDE, FAR/NEAR, BRIGHT+/-, TEXT, NEG, MIRROR, SPLIT, SAVE, RECALL
These press buttons on the side of scanning panel, which offer a free controlling for image/document transferring.
Metal painting classical black color, good finish
Folded dimension: 400*350*180mm
Setup dimension: 400*430*530mm
This visualizer with remote control to freely use what you want to do, all actions would be done.
POWER, SAVE, RECALL, LAMP, ROTATE, FREEZE, NEG, MIRROR ...
Document Visualizer
Hardware Spec | ||
Lens | Output Pixels | 8 millions, the clarity of the level >= 1200mm lines |
Rotation | 230 ° (H/V) | |
Picture | Zoom | 220x times ; optical zoom: 22x; Digital zoom: 10x |
Special features | positive and negative pictures, freeze, rotate, mirror, text image switching, brightness adjustment, etc .; auto focus, auto white balance, color / black , support split | |
Storage | yes, 32 pictures; unlimted saving to PC | |
Contrast | yes, on one screen | |
RGB i/o | DB15F/L/C *2; output resolution: XGA, SXGA; 1280 * 1024,720P, 1080P. | |
Frame Rate | 720P, 60 frames / sec for the video | |
Interfaces | RS232 | *1 |
Audio i/o | 3.5mm interface *4 (in), *1(out) | |
Video i/o | RCA*1, S-VIDEO*1 | |
Microphone (in) | Standard Microphone socket 6.3mm | |
USB2.0 | *1 | |
LED Light | 2*LED Lights at sides; and with LED backlight on the board. | |
Red & Blue Gain | yes | |
Brightness Adjustment | yes | |
Product Dimensions | 360mm * 331mm * 91mm | |
Net Weight | 2.35KG | |
Power on | Free, when power on the computer, the visualizer will auto on at same time. | |
Software Features: | ||
1. Shoot the document / picture or any objects, and make the demo on the screen. | ||
2, Support some kinds of pens to edit/annotate the file, erase/delete, save, dynamic word insert, free zoom by 1% gradient free zoom to 1000%; | ||
3. the virtual blackboard function: In the demo window can cut any content to edit/annotate | ||
4 Image effects: negative, mirror, black and white, automatic exposure, video freeze, 1: 1, full screen, left and right rotation. | ||
5, image management: support JPG, BMP, PNG, PDF format, support one key shooting in PDF file . | ||
6, Contrast function: support 2,4,9,16 split screen, add picture comparison, dynamic video previewing, support real-time touch zoom, left and right rotation. | ||
7, Record video function : all operations can be record as a video, support MP4, AVI, WMV … etc, support 1080P, 720P and full-screen mode recording. |
The package will be settled by wooden case or pallet to ensure the shipment safety,. ITATOUCH will keep communicate with our clients to arrange all, include Air (by express or airport) and Ocean shipment.
Q: What is the MOQ?
R: MOQ: 1pcs. Sample supporting.
Q: How Long Leadtime ?
R: It would be around 5~10pcs
Q: Will you teach us how to use this visualizer?
R: Yes, we will offer user manual for client reference, it could be download from our website or ask our sales to get it. any please feel free to contact us
Q: Which accessories would be included for the package of the LED Visualizer?
R: Included,
1* Remote Control & 1* Power Cable (the international standard, such as: EU, UK, US .. per usser location)
.
Q: How to order it?
R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.
