A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years
Based on your gesture,you can control the touch display, include J Zoom in / out, Rotate, Erase, Multi Tasks Witching, Write …for easy teaching and presentation.
Full touch to switch the channels
Touch the bottom to pull up, there well be the menu channels, including TV System, Android, OPS PC, HDMI 1/2/3, Sources, Display, then user could select the channels accordingly, including adjust the screen parameters.
Anti-Glared Glass Option
If user need the anti-reflective device, then the tempered glass will be handled with special technology, so please bring out when you order.
Round Corner, anti-scratch screens
Module design with LED backlight screen panel, the device is thin and narrow, include the touch panel – tempered glass.
The stylish appearance with metal drawing, die-modular polishing,
The package will be settled by wooden case or pallet to ensure the shipment safety,. ITATOUCH will keep in touch with our clients to arrange all,processes including Air (by express or airport) and Ocean shipment.
Q: Which accessories would be included for the package of this interactive touch panel?
R: the package accessories as below,
Q: What is the Lead-time?
R: Leadtime: within 10days for 1~10pcs. around 10~20days for 20~100pcs.
Q: How long time is for the warranty?
R: Usually it is one year. Certainly, three years also except the sceen panel (since the factory of screen panel just offered one year). we could talk case by case.
Q: How to order it?
R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.
Q: Does ITATOUCH provide the OS for the interactive touch screen with OPS PC ?
R: Normally offer the finish device only, certainly we could help to install a tral version (WIN 7 / WIN 10) if needed, since we are the hardware interactive touch screen manufacturer.
Q: Is there extra whiteboard software for this interactive panel?
R: Yes, ITATOUCH could offer the whiteboard software if needed, or User could download it from website.
This interactive panel is special style which with magnetic pen holds on front bottom, the design of its appearance is a simple and fashioned, and there are powerful interactive features - under andriod OS itself interactive software (if user needs) could transfer the contents between multi devices (interactive flat panels , tablet and phone ) in real-time for multipe users. Current it mainly used to office, government, hotel conference and meeting, a video display meeting for various users.
Video Camera could be attached if needs.
Application Examples:
ITATOUCH Interactive Touch Display adopts 9th generation infrared multi touch technology, high-density infrared light tube integrated PCB, which guarantee the touch sensor is accurate and smooth, offer multiple users (10points touch) good and pleased feeling.
ITATOUCH Interactive Flat Panel with built-in android OS and OPS PC are attachable, users do not need the projector again to create an interactive learning / teaching / meeting the environment, which is so easy and convenient.
IR 9th generation technology, finger & any objects touch, support 10 users writing, response fast , smoothly
LED backlight, LG /Samsung / AUO screen panel , 1920*1080p or 3840*2160 resolutions
Android 5.0 OS, 4cores CPU, 1GB/2GB RAM, WIFI. option OPS PC Intel I3 / I5 / I7, 4GB/8GB
Intelligence gesture, touch switching all, one key power on/off , auto-sensor, eye-protection, kids lock, engery saving ...
AG glass option for interactive panel, real synthetic anti-glare technology for all lifetime
Android OS with interactive transferring software, support multi screens, divided screens, gesture eraser ...
The sideback of this interactive display have more interfaces: USB, HDMI, VGA, RS232, RJ45, I/O , Microphone ... WIFI with antenna, which is very convenient to conncet with outside device, as computer, internet, video device ... etc.
Infrared 9th generation technology, finger and any objects touch screen, 4mm tempered glass, high transmittance
Fast response, write/annotate smoothly for teaching and demo presentation.
Support over 10 people write on the screen at the same time, people will enjoy the using experience.
Anti-light interference, anti-shadow, adapt to a variety of environments
Easy maintenance and replacement – self-checking software in case any problem happens.
Magnetic Attachable Pen Holds
On front bottom , there are two pen slots for attaching the pens.
Android & Windows OS
Android mainboard built-in, android 5.0 /6.0 OS , quad-core CPU, 1GB/2GB DDR3/DDR4 RAM, it also could smoothly sue the touch screen even if there is no computer connecting, including access to the internet, edit, annotate, upload /save files … etc which offer non-worried application environments.
Android OS with multi-languages, include English, Spanish, Russian, Polish, Germany, Turkey, Arabic …
OPS SLOTs for OPS PC attachable
User could select the OPS PC configuration, including Intel I3 / I5 / I7 CPU, 4GB/8GB DDR3/DDR4 RAM, 120G/256G SSD or 500GB / 1TB HDD, CJPU chipset: H61 /H81 /H110.
2K / 4K Screen Panel
The screen panel will be LCD LED backlight, 2K /1080P or 4K / 2160P display, which offers the presentation with real and vivid images and words, giving a deep impressive teaching/conference.
Screen panel Panel size 55inch 65inch 75inch 86inch Screen panel TFT screen panel, LED backlight Display (mm)(H/V) 1209.6 x 680.4 1428.48 x803.52 1650.24 x928.26 1872 x1053 Display Rate 16:09 16:09 16:09 16:09 Max resolution 1920x1080 3840x2160 3840x2160 3840x2160 Display color 16.7M 1.07B 1.07G 16.7M Pixel (mm)(H/V) 0.21×0.63 0.372*0.372 0.143(H) mm x 0.430 0.4875 x 0.4875 Brightness (nits) 300cd 400cd/m² 400cd/m² 350cd/m² Contrast 1200:1 1200:1 1100:1 1200:1 Visual angle ±178° ±178° ±178° ±176° Response time 8ms 6ms 6ms 8ms Speaker MAX power: 15W*2 Mainboard Android Mainboard (Option) Android mainboard, Clocked CPU 1.4GHz, Memory 1GHz, Flash Nand 4GB, Android 5.0 OS ; Input: Mini-YPBPR*1, Mini-AV*1, PC-AUDIO*1, VGA*1, TV-USB2.0*2, UHD1.4*1 UHD2.0*1 (only for 4K display), HDMI built-in *1; RS232*1; RJ45*1, SD Card Reader for android *1 Output: Earphone*1; AV(mini)*1; SPIDF*1; Touch USB *2 Front Interfaces: HDMI*1; VGA*1; PC-Audio*; ALL-USB*2; Touch-USB*1; Mini Microphone*1 Front Buttons: PC Power; TV Power; MENU; Source; VOL+, VOL-, Energy; Power on/off Features 1. One key to power/on offer the screen and device; automatically power off. One-key lock the display; Automatic wake-up and child-lock function OPS COMPUTER CPU Intel Core i7/i5/i3/Celeron CPU 1150-pin; Integrated HD Graphics; built-in HD audio 6(Realtek ALC661) Memory DDR3 1333Mhz 4G/8G option SSD 120G SSD (240G SSD or 500G HDD option) Wi-Fi Optional, Wi-Fi with Antenna, 802.11 b/g/n PC Ports HDMI×1, VGA×1, USB2.0×2, USB3.0×2, RJ45×1, PCAUDIO×1, MIC×1, RS232×1 Touch Technology Multi Touch Infrared technology,, 10point touch; finger or any objects touch Glass Tempered glass, 4mm, Transparency rate>95%; 32768(W) × 32768(D) ; Resolution Response speed: 5ms; Typical accuracy<1.5mm;Cursor Speed:180 d/s around; Features No drift, drive-free, waterproof, anti-dust; finger/object multi-touch, intelligence gesture recognizes etc OS Support Windows 7/ Windows 8 Whiteboard Software Option, widely used to education, conference, military etc; multi-functions and multi-languages; compatible with Windows OS Power supply Power supply AC100~240V 50 /60 HZ; Consumption: Standby <1W Consumption ≦200W ≦250W ≦300W ≦500W Environments Working: 0°C to 40°C ;Storage:-20°C to 55°C; Humidity:20%-80% RH at 40°C, non-condensing Physical Features Case Black color/ Aluminum alloy/ metal case Dimension 1291.8*799.1*81.2 1511.2*922.7*81.2 1733.2*1048.7*81.2 1979.4*1197.7*121 Mount (mm) 23.3mm 23mm 23.3mm 8.5mm Package (mm) 1495*925*245 1710*1135*245 1910*1285* 245 2150*1410*295 CBM 0.35 0.5 0.53 0.73 N/W & G/W (kg) 54 & 65kg 78 & 92kg 79 & 96kg 115& 136kg 20'GP/40'HQ 90/220pcs 55/140pcs 48/125pcs 37/95pcs Accessories ISO9001,ROHS, CE, FCC User Guide, Warranty card, Remote Control, USB Cable 3m; Power Cable 1.5m; Touch Pens /2pcs,
Company Features
1. ITATOUCH is an integrated touch screen video wall contractor integrating design, procurement and development.
2. Call Now! In Order To Meet The Market Demand, ITATOUCH Will Continually Develop New electrical display stand, video wall flat panel display, video wall with touch screen. Please See More Information On Our Website.
3. ITATOUCH aims to be an international smart interactive whiteboard exporter. Get an offer!
