+ 86 13582949978Infrared Multi Touch Screen
IR 9th generation PCB, finger touch, support 10users writing intelligence gesture, full touch to switch channels
A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years
ITATOUCH Best interactive flat panel display suppliers for government
Model#:
HT-43D NF Series
Size Range:
32”, 43”, 50”, 55”, 65”
Touch Tech:
Infrared Multi Touch 10point
Resolution:
1920x1080P
OS:
Windows
Interfaces:
USB, HDMI, VGA
Computer :
OPS PC attachable, Intel I3 /I5 /I7, 4GB/8GB
Supply Ability:
5000piece per month
Min. Order:
1piece
Payment:
T/T, Western Union, PayPal, Alipay, L/C
Shipping:
Express / Air / Sea per the requirements (Transparent and fair price, online tracking)
Port:
Shenzhen, China
Popular out-looking with multi functions and features, which mainly used for education, school, classroom, conference, military … etc
The most structure of HITATOUCH interactive panels are modular, each configuration parts (as OPS PC, driver board) are separated which is very convenient for maintenance, repair and upgrading in the future. User could just open the part which need to be changed, no need to open whole device again.
The video is showing how to attachable the OPS PC of interactive touch monitor, include the driver board part.
Welcome to offer some new ideas about the interactive displays, your suggestions would be highly appreciated!
Products Details
Mainly used to commerce, such as supermarket, hotel, restaurant, station, airport for information, menu list, instruction … checking.
2K Screen Panel
FHD 1080P, modual screen panel, LED backlignt, A+ quality
OPS PC Attachable
It have OPS PC slots to be attached, Intel I3 / I5, I7, 4GB /8GB RAM, 120G /240G SSD, WIFI
Modual Design
modual design to easy maintanence & use, wire-drawing process with painting color, black, golden
Metal frame with round corner, painting color and wire-drawing process
Modual deisgn, pull out /attached OPS PC easily to be maintanence convenience.
Front bottom with 2*USB ports, pwoer on/off & indicate light buttons.
Multi Touch Points 10 points
Finger and any objects touch screen, 4mm tempered glass, high transmittance, fast response.
Support multiple people write on the screen at the same time,
Anti-light interference, anti-shadow, adapt to a variety of environments
Easy maintains and replacement
Full touch to switch the channels.
Touch the bottom to pull up, it will have the menu channels, include TV System, Android, OPS PC, HDMI 1/2/3, Sources, Display, then user could select the channels accordingly, include adjust the screen parameters.
OPS PC attachable
This interactive flat panel with OPS SLOTs which is for OPS PC attachable.
User could select the OPS PC configuration
Intel I3 / I5 / I7 CPU, 4GB/8GB DDR3/DDR4 RAM, 120G/256G SSD or 500GB / 1TB HDD, CJPU
Chipset: H61 /H81 /H110.
Stylish Appearance
Aluminum alloy drawing frame.
Multiple colors option: Black, Golden, Sliver, White …
Super slim, narrow frame. OPS PC slots.
Multi Interfaces & Buttons
Front Interfaces: USB *2
Front buttons: Menu, Source, Vol-, Vol+
Backside interfaces: HDMI, VGA,
One key power on/off
By the remote control to power on / off the touch screen and OPS PC for convenience use.
SPECIFICATION
| Screen panel | |||||
| Panel size | 32inch | 43inch | 50inch | 55inch | 65inch |
| Screen panel | TFT screen panel, LED backlight | ||||
| Display (mm)(H/V) | 697.69 *392.3 | 941.2 x527.4 | 1095.1x615.5 | 1209.6x680.4 | 1538.8*865.6 |
| Display Rate | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 |
| Max resolution | 1920x1080 | 1920x1080 | 1920x1080 | 1920x1080 | 1920x1080 |
| Display color | 8 bit | 10 bit | 10 bit | 10 bit | 10 bit |
| Brightness (nits) | 320cd/㎡ | 320cd/㎡ | 320cd/㎡ | 350cd/㎡ | 470cd/㎡ |
| Contrast | 1400:1 | 4000:1 | 4000:1 | 4000:1 | 1400:1 |
| Visual angle | ±178° | ±178° | ±176° | ±176° | ±176° |
| Response time | 8ms | 6.5ms | 6.5ms | 6.5ms | 6.5ms |
| Speaker | MAX power: 15W*2 | ||||
| Mainboard | |||||
| TV System | PAL, NTSC/SECAM (Optional) | ||||
| Input: RFx1,Y Pb Pr *1; CVBS*2; CVBS Audio L/R *2; PC Audio*1; VGA*1; Media USB2.0*1; HDMI*1; HDMI built-in *1 | |||||
| Output: Earphone*1； AV*1; HDMI*1； HDMI built-in *1; PC USB*2 | |||||
| Buttons on side frame：POW、IN、MENU、VOL+、VOL-、CH+、CH-、PC | |||||
| Input on side frame: USB2.0 *2 | |||||
| OPS COMPUTER | |||||
| CPU | Intel Core i7/i5/i3 processor, intel H81 chipset | ||||
| Memory | DDR3 1600Mhz 4G/8G option | ||||
| SSD | 120G SSD (240G SSD or 500G HDD option) | ||||
| Wi-Fi | Optional, Wi-Fi with Antenna, 802.11 b/g/n | ||||
| PC Ports | HDMI*1, RS232*1, LAN*1, USB3.0*2, USB2.0*4, WIFI with antenna | ||||
| Touch Technology | |||||
| Multi Touch | Infrared technology, support 10point ~32point touch; finger or any objects touch | ||||
| Glass | Tempered glass, 4mm, Transparency rate>95%; 32768(W) × 32768(D) ; | ||||
| Resolution | Response speed: 5ms; Typical accuracy<1.5mm;Cursor Speed:180 d/s around; | ||||
| Features | No drift, drive-free, waterproof, anti-dust; finger/object multi-touch, intelligence gesture recognizes etc | ||||
| OS | Support Windows 7/ Windows 8 | ||||
| Whiteboard Software | Option, widely used to education, conference, military etc; multi-functions and multi-languages; compatible with Windows OS | ||||
| Power supply | |||||
| Power supply | AC100~240V 50 /60 HZ; Consumption: Standby<1W | ||||
| Consumption | ≦60W | ≦80W | ≦100W | ≦120W | ≦250W |
| Environments | Working: 0°C to 40°C ;Storage:-20°C to 55°C; Humidity:20%-80% RH at 40°C, non-condensing | ||||
| Physical Features | |||||
| Case | Black color/ Aluminum alloy/ metal case | ||||
| Dimension | 795.4*490*116 | 1018.4*606.5*72.8 | 1174.9*697.3*73.27 | 1287.9*761.4*73.2 | |
| Package (mm) | 890*575*210 | 1150*730*225 | 1325*835*235 | 1495*925*235 | |
| N/W & G/W (kg) | 23 & 28kg | 29 & 36kg | 30 & 38kg | 54 & 65kg | 79 & 94kg |
| Accessories | ISO9001, CCC, CE, FCC | ||||
| User Guide, Warranty card, Remote Control, USB Cable 3m; Power Cable 1.5m; Touch Pens /2pcs, | |||||
Package
The package will be settled by wooden case or pallet to ensure the shipment safety,. ITATOUCH will keep communicate with our clients to arrange all, include Air (by express or airport) and Ocean shipment.
Container loading - the package with pallet and plastic flim to anit-damaged and waterproof
The workers are setting the safety strips to avoid shocking damaged during shipment.
Air shipment for small order quantiy - settle wooden case or pallet with stripe to ensure safety.
FAQ
Q: Which accessories would be included for the package of this interactive touch panel?
R: the package accessories as below,
1* Remote Control
1* USB Cable
1* Power Cable (the international standard, such as: EU, UK, US .. per usser location)
1* USB Cable
1* Power Cable (the international standard, such as: EU, UK, US .. per usser location)
1* HDMI Cable (if device with HDMI interfaces)
2* Touch Pens
2* Touch Pens
1* Wall Mounted
Q: What is the Lead-time?
R: Leadtime: within 10days for 1~10pcs. around 10~20days for 20~100pcs.
Q: How long time is for the warranty?
R: Usually it is one year. Certainly, three years also except the sceen panel (since the factory of screen panel just offered one year). we could talk in case by case.
Q: How to order it?
R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.
Q: Does ITATOUCH provide the OS for the interactive touch screen with OPS PC ?
R: Normally offer the finish device only, certainly we could help to install a tral version (WIN 7 / WIN 10) if needs, since we are the hardware interactive touch screen manufacturer.
Q: Is there extra whiteboard software for this interactive panel?
R: Yes, ITATOUCH could offer the whiteboard software if need, or User could download it from website.
