Professional manufacture interactive flat panel display lcd touch screen celulares
Product Details
ITATOCUH develop a commerce display with infrared touch screen, and which has ULTRA NARROW FRAME
only 12mm
Color customized: White / Black
The default configuration is Android OS, 2GB RAM, 4GB/8GB Flash Nandi
OPS PC Intel I3, I5, I7 option
ITATOUCH LCD digital signage display adopt LED back light screen panel with FHD 1080P/ UHD 4K resolution, Android network LAN.
The materials of the case are aluminum frame with drawing painted treatment, and metal backside with painted color, perfect finish. Infrared Multi Touch Screen Technology
CUSTOMIZED & OEM Supporting!
Interactive Boards with Black Color - and the backside with OPS PC
Education Android Solution Option - Android 5.0 / 6.0 /8.0 OS
The Main Features:
White Color IR Touch Panel with Stand Table
The color to be customized, include the stand with wheels option
Infrared Touch Display
The size range of wall mounted commerce digital display : 32”, 43“, 49"/50", 55", 65"
Factory LCD Multi Touch Screen Production Line
ITA TOUCH factory area 3500 square meters, own enough capacity for your touch screen order, welcome to joint us to expand more markets.
Specification
The Technical Parameter for Interactive Multi Touch Display
Specification:
|
Display Size
|
32"
|
43"
|
49"
|
55"
|
65"
|
||||
|
Product Dimension
|
779*475*61.6
|
1010*603*75.8
|
1150.5*682*77.2
|
1289*760*81.6
|
1508*883*85.6
|
||||
|
Active area
|
696*392
|
943.2.4*531
|
1077*607.5
|
1209*680
|
1427.08*805.32
|
||||
|
Resolution
|
1920*1080
|
1920*1080
|
1920*1080
|
1920*1080
|
1920*1080
|
||||
|
Display Ratio
|
16:9
|
16:9
|
16:9
|
16:9
|
16:9
|
||||
|
Contrast Ratio
|
1400:1
|
1400:1
|
3000:1
|
4000:1
|
4000:1
|
||||
|
Brightness
|
360 cd/m²
|
360 cd/m²
|
380 cd/m²
|
380cd/m²
|
350 cd/㎡
|
||||
|
Response time
|
6ms
|
6ms
|
6.5ms
|
5.5ms
|
6.5ms
|
||||
|
Color
|
16.7M
|
16.7M
|
16.7M
|
16.7M
|
16.7M
|
||||
|
Viewing angle
|
178°
|
178°
|
178°
|
178°
|
178°(H) / 178°(V)
|
||||
|
Stereo speaker
|
10W, 8Ω
|
10W,8Ω
|
10W, 8Ω
|
10W,8Ω
|
10W,8Ω
|
||||
|
Android Solutions
|
Rk3368 eight core 64 bit cortex-a53, up to 1.5g in frequency, 2G in memory and 8g in flash memory
|
||||||||
|
Interfaces: HDMI-compatible×1,VGA×1,USB2.0×2,RJ45×1,AUDIO×1，WIFI×1
|
|||||||||
|
PC Solutions Option
|
Chipset InterlHM76/ H81/H110, Intel J1900/ I3 /I5 CPU, 4G memory, 120G SSD, Wi-Fi Interfaces: USB*4；HDMI-compatible*1, DVI*1, VGA*1,
RJ45*1,RS232*1, MIC*1 |
||||||||
|
Multi Touch Technology
|
Infrared multi touch screen panel , support 6point - 10point touch; finger or any objects touch
|
||||||||
|
Tempered glass, 4mm, Transparency rate>95%; 32768(W) × 32768(D) ;
|
|||||||||
|
Response speed: 5ms; Typical accuracy<1.5mm;Cursor Speed:180 d/s around;
|
|||||||||
|
No drift, drive-free,waterproof,anti-dust;finger/object multi-touch, intelligence gesture recongize etc
|
|||||||||
|
Support Windows 7/ Windows 8 / Windows 10
|
|||||||||
|
Shell
|
Color and shape to be customized - the default : Aluminum frame, metal case backside.4mm Tempered Glass
|
||||||||
|
Work environment
|
Temperature: working 0℃～40℃, Storage: -20℃～55℃ ; Humidity: 10%～90% RH Non-Condensing, Storage: 20%～80% RH Non-Condensing
|
||||||||
|
The day longest time : 7/24 (days/hours)
|
|||||||||
|
Power
|
AC 100-240V 50/60HZ; Stand by ≤1W
|
||||||||
|
≤60W
|
≤100W
|
≤130W
|
≤130W
|
≤150W
|
|||||
|
Quality appliance
|
CE, FCC, ROHS, ISO9001, ISO14000
|
||||||||
|
Accessories
|
wall mounted, Power Cable, User Manual
|
||||||||
Remark: just for reference, the actual parameters will be some difference per different components
Configuration of Android boards:
1. Rk3288 Quad Core Cortex-A17, frequency up to 1.8GB, memory 2GB, flash Storage: 8GB
2. Rk3399 Double Cortex-A72 + four cortex-A53, frequency up to 2.0 GHz, memory 2GB, flash storage: 8GB
