ITATOUCH commerce interactive smart boards multi for office

Company Advantages
1. Before ITATOUCH capacitive multi touch screen leaves a warehouse, every aspect will be analyzed and inspected to make sure that the product is perfect in every way. Ita Touch products are perfectly designed by our professional designers
2. As the society changing, the quality of interactive smart boards remains the same as before. Sample could be supported, but will charge some cost for design and special labour
3. interactive smart boards is intensively developed by Shenzhen ITA Touch Technology Co., LTD due to its superior characteristics of capacitive multi touch screen . Ita Touch Interactive Boards support multiple users
4. All of our interactive smart boards are featured by capacitive multi touch screen and have properties like interactive smart boards prices . Produced with nano surface, the screen is highly sensitive
5. Due to its capacitive multi touch screen , interactive smart boards has been widely used in many applications such as interactive smart boards prices . With interactive intelligence features, Ita Touch can offer you a convenient and smart experience





The Interactive Touchscreen Panel adopts latest infrared touchscreen technology, supporting 10-32 points touch. It is designed to provide touch-screen interfaces with the same sort of flexibility and usability that a traditional mouse and keyboard provide, while also providing for more intuitive and seamless user experience. In addition, it supports the Android system and optional Windows OS OPS PC, which can give users more APP choices and using experiences. With its wide ranges of sizes, frames, and customized optional hardware equipment, it can offer more solutions for education, conference, business presentation, etc.











Screen Panel	Panel size	55inch	65"	75"	86"
	Screen Panel	TFT-LED   panel	D-LED   LG panel	D-LED   LG panel	D-LED   LG panel
	Display (mm)(H/V)	1209.6   X 680.4	1428.48   x803.52	1649.6*927.9	1895.04x1065.96
	Display Rate	16:09	16:09	16:09	16:09
	Max resolution	1920x1080	3840x2160	3840x2160	3840x2160
	Display color	16.7M   8bit	1.07B   8bit	1.07B   10bit	1.07B   10bit
	Pixel (mm)(H/V)	0.21   x 0.63	0.372x   0.372	0.429   x 0.429	0.4935   x 0.4935
	Brightness (nits)	350cd/㎡	500cd/m²	400cd/m²	350cd/m²
	Contrast(typical)	4000:1	4000:1	4000:1	4000:1
	Visual angle	±176°	±178°	±178°	±178°
	Response time	8ms	6ms	6ms	8ms
	Speaker	MAX   power: 15W*2
Android    System	Mainboard	Android   5.01 OS Contex A53, Mail450MP4 Quad-core CPU, 1.4GHz, 2GB DDR3 RAM,  16GB Flash Nandi , IEEE802.11 a/b/g/n Dual   Band  5 GHz
	Input	HDMI*2,  VGA*1,  YPBPR*1,  TV*1, AV *1 (Mini Jack in 3.5mm)    USB 3.0*2,   TOUCH-USB*1,   RS232*1,   SD/TF card*1 (support 128GB MAX) ,   RJ45 LAN   *1,   WIFI *1,  OPS-SLOT*1
	Output	Earphone*1, Mini-AV*1;    Coaxial *1, HDMI*1 (option) , VGA*1 (option)
	Front frame	Interfaces:   HDMI*1,  USB-Media *1, USB-PC*1,  USB-TOUCH*1                                        Buttons: POWER, SOURCE, MENU, VOL+, VOL-, CH-, CH+, PC, ES, ENTER,   HOME
Video Features		3D   digital comb filter、3D image motion noise reduction、3D Motion Adaptive   Digital comb filter
Touch System	Multi   Touch	Infrared   technology, support 10~20point touch; finger or any objects touch
	Glass	Tempered   glass, 4mm, Transparency rate>95%; 32768(W) × 32768(D) ;
	Resolution	Response   speed: 5ms;  Typical accuracy<1.5mm;Cursor Speed:180 d/s around;
	Features	No   drift, drive-free,waterproof,anti-dust;finger/object multi-touch,   intelligence gesture recongize etc
	OS	Support   Windows 7/ Windows 8
OPS PC (option)	CPU	Intel®HM86   Chipset I3-4000M /I5-4200M /I7 -4600M,    Integrated HD Graphics;built-in HD audio 6(Realtek ALC661)
	Memory	DDR3   1333Mhz 4G/8G  option
	SSD	128G   /256G SSD
	Wi-Fi	Wi-Fi   with Antenna, 802.11 b/g/n
	PC Ports	4*USB3.0,   2*USB2.0, 1*HDMI, 1*VGA, 1*RJ45 1000M internet, 1*Line out, 1*MIC
Power	Power   supply	AC100~240V   50 /60 HZ; Consumption: Standby <1W
	Max consumption	≦120W	<=250W	<=300W	<=350W
Environment		Working:   0°C to 40°C ;Storage:-20°C to 55°C;  Humidity:20%-80% RH at 40°C,   non-condensing
Appearance		Black color/ Metal Shell
Package Dimension	Dimesion	1259*771*87.5	1514.8*102.6*934.7	11739*1063*124mm	1989.6*114.3*1201.9
	Package (mm)	1455*195*935mm	1680*1050*220mm	1900*250*1195mm	2134*1289*240mm
	N/W & G/W (kg)	47   & 61kg	49   & 65kg	76   & 88kg	84   & 108kg
Quality Certificate		ISO9001,   CE, FCC, RoHs
Accessories		Warranty card, Remote Control, USB Cable   1.5m; Power Cable 1.8m; VGA cable 1.5m, Touch Pens /2pcs,

Company Features
1. With Shenzhen ITA Touch Technology Co., LTD's strong strength in science and technology, it benefits for the development of interactive smart boards .
2. Shenzhen ITA Touch Technology Co., LTD continues to lead the market with 4k touch screen monitor that gives customers in the world a competitive edge. Call!
