the wall mounted Advertising display applied to factory production lines for the process instruction.
The color and out-looking can be customized.
White/black, green ... etc.
A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years
ITATOUCH New interactive display for business for education
Size Range:
19” 21.5” 23” 27” 32” 43” 49” 55” 65“
Resolution:
1920x1080
OS:
Android system
Interfaces:
USB3.0, HDMI, MIC, RS232, VGA
Computer :
Cortex A20, Dual-core 1.2GHz CPU, 1GB DDR3
Supply Ability:
2000Piece/month
Min. Order:
1Piece
Payment:
TT
Shipping:
By sea, by air
Application Scope
ITATouch's Digital Signage Totem has been widely used in many industries.While providing quality products, ITATouch is dedicated to providing personalized solutions for customers according to their needs and actual situations.
1. interactive display adopt large interactive touch screen materials, generate features such as screen interaction .
2. Its quality is guaranteed through the implementation of our rigorous control process for production.
3. The product has passed ISO 90001 quality certification.
4. This product will effectively help align people's feet and finally significantly help correct their gait and improve their body posture.
5. Using this product means fewer employee costs. By adding this product to an operation, fewer employees are needed to get the job done.
Wall Mounted Commercial LCD Panel Touch Screen Digital Billboard LED Advertising Display
Product Details
The indoor digital advertising display widely uses for Restaurant, Hotel, Airport, Gas, Railway and Bus Station, Shopping Store, Supermarket for Advertisement Information Playing and Inquiries .. etc.
Touch Screen Display
Applied to Production Lines
The Main Features of Wall Mounted Digital Display
The materials of the case are aluminum frame with drawing painted treatment and metal backside with painted color, perfect finish. Interactive Touch Screen Option – Infrared / Capacitive Multi-Touch Technology, finger or any objects touching.
* 1080P Full HD Panel Display
* Support LAN management control, directly issue any by severing computer.
* Support flash subtitle, Log management, time on/off
* Multi-display modes; Horizontal, Vertical, Full and Divided displaying screens.
* Security Design, industrial mainboard, and 4mm tempered glass
* Support full media format files
ITATOCUH offers indoor and outdoor digital display, which includes wall-mounted, floor stand installation, and supports the customized one, such as configuration, shape, color or materials, even totem image, Etc.
Hardware & Software
Hardware: Aluminum Frame with Metal / Plastic painting color, support customized shape
Net-working management software
Each terminal/unit installed, the management software to be installed computer sever if needs.
The following dimension of the sketch is for 21.5 inches floor stand display
other sizes option - 15.6", 19", 32", 43", 50", 55", 65", 75"
Customized Clarification:
a series of dimensions for various sizes, when the shape and configurations of the free-standing digital signage are different, it will be a little change measurement.
![]()
![]()
The change / customized include the following
1. Out-looking & Colorful
2. Configurations different: android LAN (default equipment), PC built-in, touch monitor only
3. Touch Screen built-in, Infrared or Capacitive multi-touch
4. Built-in Camera (MOQ: 50pcs)
5. Built-in printer, card reader ... etc.
Specification
The Technical Parameter for Advertising Display
Remark: just for reference, the actual parameters will be some difference per different components
| Display Size | 21.5" | 32" | 43" | 50" | 55" | 65" | |
| Product Dimension | 552*342.9*47.2 | 786*480.6*62.8 | 1022*615*62.8 | 1128*651.2*71.1 | 1306*777*63.8 | to be advised | |
| Active area | 476.64*268. | 727.4*429 | 960.4*560.4 | 102008*575 | 1209.6*681 | 1428.48x803.52mm | |
| Resolution | 1920*1080 | 1366*768 | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 | |
| Display Ratio | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 | |
| Contrast Ratio | 1000:1 | 1400:1 | 1400:1 | 3000:1 | 4000:1 | 4000:1 | |
| Brightness | 300cd/m² | 360 cd/m² | 360 cd/m² | 380 cd/m² | 380cd/m² | 350 cd/㎡ | |
| Response time | 5 ms | 6ms | 6ms | 6.5ms | 5.5ms | 6.5ms | |
| Color | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | |
| Viewing angle | 178° | 178° | 178° | 178° | 178° | 178°(H) / 178°(V) | |
| Stereo speaker | 5W,8Ω | 10W, 8Ω | 10W,8Ω | 10W, 8Ω | 10W,8Ω | 10W,8Ω | |
| Android LAN Work Solutions | |||||||
| mainboard | Cortex A20, Dual-core 1.2GHz CPU, 1GB DDR3, 8GB Flash Nand, Android OS 4.2.2 | ||||||
| Internet | RJ45, 1*10/100M Ethernet ; Wi-Fi, 802.11 1x1 BGN+BT | ||||||
| Input | USB2.0*2, TF*1, RJ45*1, DC12V*1 | ||||||
| Output | HDMI*1, MINI AV*1 | ||||||
| Features | Support all the usual audio formats | ||||||
| Support music library, tag search, online streaming media | |||||||
| Video | 3D 1080P; Video Decode AVI(h.264,DIVX,XVID,RM,RMVB,MKV,WMV,MOV,MP4,MPEG | ||||||
| Flash | Support Adobe Flash V11.1 or Later | ||||||
| Picture | Support JPEG, GIF, PNG, BMP files; Picture rotating, zooming out, support painting,(Gallery) | ||||||
| others | Google Brower, Google APP, Market/APP Store download APK and games Google Map, Email | ||||||
| Calculator, Calendar, files manager; Office documents (TXT, PDF, Office Doc/Xls/PPT editor) | |||||||
| Support flash subtitle, Log management, time on/off, | |||||||
| Normal LAN built-in PC Solutions | |||||||
| Mainboard | Sigma 8635 mainboard ( LAN system); X86 mainboard ( built-in PC) | ||||||
| Memory | SD card - 4GB option (can be expanded to 32GB) | ||||||
| Network | IEEE802.3 10/100M Ethernet LAN | ||||||
| Input | USB2.0*1; RJ45*1 | ||||||
| Option | CF *1; SD *1 | ||||||
| Audio | Support full format file(1080P) | ||||||
| Video | support MPG,MPG-1,MPG-2,MPG-4,AVI,MP4,DIV,TS,TRP,MKV,MOV,WMV,RM,RMVB | ||||||
| picture | Support JPEG,GIF,PNG,BMP files | ||||||
| others | Security design; multi-display modes; | ||||||
| Support flash subtitle, Log management, time on/off, display instant messaging | |||||||
| Built-in PC (option) | |||||||
| PC | Intel J1900/ I3 /I5 CPU, 4G memory, 500G HDD Wi-Fi with Antenna (option) | ||||||
| Interfaces | Interfaces: USB*4；HDMI*1, DVI*1, VGA*1, RJ45*1,RS232*1, MIC*1 | ||||||
| Touch Screen Option | |||||||
| Touch Screen | Optional, Infrared multi touchpoints, Finger touch, gloved hand, or any opaque objects | ||||||
| Case | Metal backside case, Aluminum Frame, 4mm Tempered Glass | ||||||
| Work environment | Temperature: 0℃～40℃: Humidity:10%～90% | ||||||
| Power | AC 100-240V 50/60HZ; Stand by ≤1W | ||||||
| ≤40W | ≤60W | ≤100W | ≤130W | ≤130W | |||
| Quality appliance | CE, FCC, ROHS | ||||||
| Accessories | CD, remote control, cables, user instruction | ||||||
The wall-mounted indoor display production lines: 15.6", 19”， 21.5“， 24”， 27“， 32”， 43“...
Packing
Small Qty Order (1~5pcs) to be Air shipping EXPRESS /DHL/FEDEX/UPS...
Bulks (Above 10pcs) to be sea shipment.
