top rated boards projected matrix ITATOUCH Brand touch screen video wall supplier
1. touch screen video wall meets the requirement of present most advanced electrical display stand. Ita Touch-Start your Intelligent Life
2. Under high quality control at all levels, the product is absolutely superior in its quality. Intelligent products can be found in Ita Touch
3. Shenzhen ITA Touch Technology Co., LTD can always accurately grasp the trend of consumption upgrade in smart interactive whiteboard field.
Outdoor LCD Dual Screens Display Totem
It presents a whole device for customer reference, waterproof, air-conditioner , high brightness 2000nits.
Basical Features
* 1080P Full High difinition screen panel
* High brightness screen panel: 1500 ~2000nits
* Waterproof , IP65
* Temperature control : cooling system / air - conditioner
* Auto-light sensor to adjust the brightness.
* Support LAN management documents by Remote Control
* Support flash subtitle, Log management, time on/off
* Multi-display modes; Horizontal, Vertical, Full and Divided displaying
* Security Design, industrial mainboard, and tempered glass
* Support full media format files
* Interfaces: HDMI, VGA
The high quality outdoor floor totem from perfect finish ...
Left back finish, round corner
Right front finish, vertical /round corner
Backside with wall mounted
| Phisical Feature | Case | 1.5mm galvanized sheet with special powder to protect the surface above 7 years |
| Waterproof design, IP55 grade | ||
| Product | 600*415*120mm(L*W*H) | |
| Display area | 473*296mm(L*W) | |
| Glass | 6mm tempered glass; Light transmittance ≥ 98% | |
| Screen Panel | Display size | 21.5” |
| Display Rate | 16:09 | |
| Resolution | 1920*1080 | |
| Brightness | 1000nits | |
| Viewing | 178°/178° | |
| Light Sensor | Automatically adjust the brightness | |
| Backlight | LED backlight, TFT screen panel | |
| Touch Screen | Capacitive Technology | Projected capacitive 10point touch, finger touch |
| PC | Mainboard | Intel I3 CPU, 4G RAM, 128G SSD; WIFI |
| Managment System | support the program publicing via the network; update/playback the program by U disk | |
| Interfaces | output | HDMI, VGA |
| Input | 4*USB, 2*RS232, 2*SATA interface | |
| Electrical performance | Power | Induatrial power supply |
| Speaker | 2*5W, high quality waterproof speaker | |
| Lightning arrester | Three lightning protection | |
| Leakage protector | yes | |
| timer | Switching can be set by day/week/month, customiable | |
| Thermolysis | Intelligent air-cooling & heating system | Intelligent cooling system - the mainboard with sepcail design, which can automatically adjust wind speed |
| Intelligent temperature control system - automatically turn off the display when temperature to be 65℃ | ||
| Envirnoment | Working Temperature | -30℃~+50℃ |
| Working Humidity | 5%~95% | |
| Working Power | AC 220V/50Hz | |
| Consumption | 150 W | |
| Others | Special features | Anti-dust & Anti - theft design |
The package will be settled by wooden case or pallet to ensure the shipment safety, ITATOUCH will keep communicate with our clients to arrange all, include Air (by express or airport) and Ocean shipment.
Container loading - the package with pallet and plastic film to anit-damaged and waterproof
The workers are setting the safety strips to avoid shocking damaged during shipment.
Air shipment for small order quantity - settle wooden case or pallet with stripe to ensure safety.
Q: Which accessories would be included for the package of this interactive touch display?
R: the package accessories as below,
1* Power Cable (the international standard, such as: EU, UK, US .. per usser location)
Q: What is the MOQ & Lead-time?
R: MOQ: 1pcs, Leadtime: within 30days. customized one.
Q: How long time is for the warranty?
R: Usually it is one year. Certainly, three years also except the sceen panel (since the factory of screen panel just offered one year). we could talk in case by case.
Q: How to order it?
R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.
Q: Does it include remote control managment software ?
R: We offer the programme with the basic features, such as: flash player, divided screen, subtitle, log managment, time on/off ... etc.
