A Professional Manufacturer of Smart Interactive Screens For More Than 10 Years
info@itatouch.com |
+ 86 13582949978
video wall flat panel display laser portable touch screen video wall manufacture
- Based on the implementation of advanced talent reserve strategy, ITATouch introduces a large number of outstanding technical and management talents. They contribute to our development.
- ITATouch has built a comprehensive service model with advanced concepts and high standards, so as to provide systematic, efficient and complete services for consumers.
- ITATouch always adheres to the strategic orientation of 'people-oriented, efficient, pragmatic and sustain-developed'. We focus on sincerity-based business and technological innovation during development. To gain mutual benefit, we strengthen the partnerships at home and abroad.
- ITATouch was founded in 2009. We own an advanced production and R&D center equipped with comprehensive supporting facilities after years of exploration. We are able to provide more high-quality products for the majority of customers.
- ITATouch's sales network covers multiple provinces, regions, and cities across the country. And the sales volume has ranked top for many years.
1. touch screen video wall uses video wall flat panel display materials to achieve good effects with different styles. One touch gives you convenience
2. electrical display stand have always found a traditional use in the video wall with touch screen industries, due the free standing interactive whiteboard of the material. Technology Innovation, Intelligent Life
3. smart interactive whiteboard is described mobile tv stand for sale by our clients. Ita Touch-Start your Intelligent Life
4. The market share of the product is increased steadily, showing a promising application future. One Screen, One Ita Touch
5. With diverse features, this product suits the modern requirements of the market.
The interactive touch panel with table stand is widely used for supermarket, shopping mall, hotel, bank, station, shopping for information inquiry and instructions.
Table Stand for Interactive Touch Digital Display
This is fixed table stand with adjustable slanted for the interactive display, the slanted degree could be lift from 45 ~85 degree by hand working.
This stand is widely used for hotel, supermarket, store, airport, station for commerce information or inquiry.
ITATOUCH offer various styles of interactive displays for different applications, include table stand, customized supporting. list three kinds of popular models for reference.
Style 1 - Infrared Interactive Panels with table stand, black painting color - OPS PC attachable, I3 /I5 /I7, 4GB RAM
Style 2 - Capacitive Touch Screen Display with table stand, white color painting - Android OS 2GB RAM
Sytle 3 - Round frame Infrared Interactive Display with table stand, Sliver color painting - Computer built-in , I3/I5/I7
Infrared / Capacitive Touch Screen Panels
Finger and any objects touch screen, 4mm tempered glass, high transmittance, fast response.
Support multiple people write on the screen at the same time,
Anti-light interference, anti-shadow, adapt to a variety of environments
Easy maintains and replacement
Full touch to switch the channels.
Touch the bottom to pull up, it will have the menu channels, include TV System, Android, OPS PC, HDMI 1/2/3, Sources, Display, then user could select the channels accordingly, include adjust the screen parameters.
OPS PC attachable
This interactive flat panel with OPS SLOTs which is for OPS PC attachable.
User could select the OPS PC configuration
Intel I3 / I5 / I7 CPU, 4GB/8GB DDR3/DDR4 RAM, 120G/256G SSD or 500GB / 1TB HDD, CJPU
Chipset: H61 /H81 /H110.
Stylish Appearance
Aluminum alloy drawing frame.
Multiple colors option: Black, Golden, Sliver, White …
Super slim, narrow frame. OPS PC slots.
Multi Interfaces & Buttons
Front Interfaces: USB *2
Front buttons: Menu, Source, Vol-, Vol+
Backside interfaces: HDMI, VGA,
One key power on/off
By the remote control to power on / off the touch screen and OPS PC for convenience use.
| Screen panel | |||||
| Panel size | 32inch | 43inch | 50inch | 55inch | 65inch |
| Screen panel | TFT screen panel, LED backlight | ||||
| Display (mm)(H/V) | 697.69 *392.3 | 941.2 x527.4 | 1095.1x615.5 | 1209.6x680.4 | 1538.8*865.6 |
| Display Rate | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 |
| Max resolution | 1920x1080 | 1920x1080 | 1920x1080 | 1920x1080 | 1920x1080 |
| Display color | 8 bit | 10 bit | 10 bit | 10 bit | 10 bit |
| Brightness (nits) | 320cd/㎡ | 320cd/㎡ | 320cd/㎡ | 350cd/㎡ | 470cd/㎡ |
| Contrast | 1400:1 | 4000:1 | 4000:1 | 4000:1 | 1400:1 |
| Visual angle | ±178° | ±178° | ±176° | ±176° | ±176° |
| Response time | 8ms | 6.5ms | 6.5ms | 6.5ms | 6.5ms |
| Speaker | MAX power: 15W*2 | ||||
| Mainboard | |||||
| TV System | PAL, NTSC/SECAM (Optional) | ||||
| Input: RFx1,Y Pb Pr *1; CVBS*2; CVBS Audio L/R *2; PC Audio*1; VGA*1; Media USB2.0*1; HDMI*1; HDMI built-in *1 | |||||
| Output: Earphone*1； AV*1; HDMI*1； HDMI built-in *1; PC USB*2 | |||||
| Buttons on side frame：POW、IN、MENU、VOL+、VOL-、CH+、CH-、PC | |||||
| Input on side frame: USB2.0 *2 | |||||
| OPS COMPUTER | |||||
| CPU | Intel Core i7/i5/i3 processor, intel H81 chipset | ||||
| Memory | DDR3 1600Mhz 4G/8G option | ||||
| SSD | 120G SSD (240G SSD or 500G HDD option) | ||||
| Wi-Fi | Optional, Wi-Fi with Antenna, 802.11 b/g/n | ||||
| PC Ports | HDMI*1, RS232*1, LAN*1, USB3.0*2, USB2.0*4, WIFI with antenna | ||||
| Touch Technology | |||||
| Multi Touch | Infrared technology, support 10point ~32point touch; finger or any objects touch | ||||
| Glass | Tempered glass, 4mm, Transparency rate>95%; 32768(W) × 32768(D) ; | ||||
| Resolution | Response speed: 5ms; Typical accuracy<1.5mm;Cursor Speed:180 d/s around; | ||||
| Features | No drift, drive-free, waterproof, anti-dust; finger/object multi-touch, intelligence gesture recognizes etc | ||||
| OS | Support Windows 7/ Windows 8 | ||||
| Whiteboard Software | Option, widely used to education, conference, military etc; multi-functions and multi-languages; compatible with Windows OS | ||||
| Power supply | |||||
| Power supply | AC100~240V 50 /60 HZ; Consumption: Standby<1W | ||||
| Consumption | ≦60W | ≦80W | ≦100W | ≦120W | ≦250W |
| Environments | Working: 0°C to 40°C ;Storage:-20°C to 55°C; Humidity:20%-80% RH at 40°C, non-condensing | ||||
| Physical Features | |||||
| Case | Black color/ Aluminum alloy/ metal case | ||||
| Dimension | 795.4*490*116 | 1018.4*606.5*72.8 | 1174.9*697.3*73.27 | 1287.9*761.4*73.2 | |
| Package (mm) | 890*575*210 | 1150*730*225 | 1325*835*235 | 1495*925*235 | |
| N/W & G/W (kg) | 23 & 28kg | 29 & 36kg | 30 & 38kg | 54 & 65kg | 79 & 94kg |
| Accessories | ISO9001, CCC, CE, FCC | ||||
| User Guide, Warranty card, Remote Control, USB Cable 3m; Power Cable 1.5m; Touch Pens /2pcs, | |||||
The package will be settled by wooden case or pallet to ensure the shipment safety,. ITATOUCH will keep communicate with our clients to arrange all, include Air (by express or airport) and Ocean shipment.
Container loading - the package with pallet and plastic flim to anit-damaged and waterproof
The workers are setting the safety strips to avoid shocking damaged during shipment.
Air shipment for small order quantiy - settle wooden case or pallet with stripe to ensure safety.
Q: Which accessories would be included for the package of this interactive touch panel?
R: the package accessories as below,
1* USB Cable
1* Power Cable (the international standard, such as: EU, UK, US .. per usser location)
2* Touch Pens
Q: What is the Lead-time?
R: Leadtime: within 10days for 1~10pcs. around 10~20days for 20~100pcs.
Q: How long time is for the warranty?
R: Usually it is one year. Certainly, three years also except the sceen panel (since the factory of screen panel just offered one year). we could talk in case by case.
Q: How to order it?
R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.
Q: Does ITATOUCH provide the OS for the interactive touch screen with OPS PC ?
R: Normally offer the finish device only, certainly we could help to install a tral version (WIN 7 / WIN 10) if needs, since we are the hardware interactive touch screen manufacturer.
Q: Is there extra whiteboard software for this interactive panel?
R: Yes, ITATOUCH could offer the whiteboard software if need, or User could download it from website.
Company Features
1. Shenzhen ITA Touch Technology Co., LTD has spent years concentrating on touch screen video wall which is manufactured based on superb technology and fine workmanship.
2. Shenzhen ITA Touch Technology Co., LTD is able to supply customers with state-of-art electrical display stand product by its fortified R&D team.
3. Shenzhen ITA Touch Technology Co., LTD persists in the service theory of video wall flat panel display. Check now!
