video wall flat panel display network light touch screen video wall manufacture

Company Advantages
1. Interactive products, Efficient communication. ITATOUCH material for video wall flat panel display is different from other companies' material and it's better.
2. Ita Touch provides you with highly intelligent life. ITATOUCH will promote innovation work, and strive to develop more, newer and better products.
3. Ita Touch-Start your Intelligent Life. Featuring comfort and functionality the offered stools are one of the best selling products in the range of touch screen video wall,video wall with touch screen.
4. One Screen, One Ita Touch. The integration of free standing interactive whiteboard and mobile tv stand for sale makes a popular electrical display stand,prices of interactive smart boards among customers.

The interactive touch panel with table stand is widely used for supermarket, shopping mall, hotel, bank, station, shopping for information inquiry and instructions.

Table Stand for Interactive Touch Digital Display

This is fixed table stand with adjustable slanted for the interactive display, the slanted degree could be lift from 45 ~85 degree by hand working.

This stand is widely used for hotel, supermarket, store, airport, station for commerce information or inquiry.

ITATOUCH offer various styles of interactive displays for different applications, include table stand, customized supporting. list three kinds of popular models for reference.

Screen panel
Panel size	32inch	43inch	50inch	55inch	65inch
Screen panel	TFT screen panel, LED backlight
Display (mm)(H/V)	697.69 *392.3	941.2 x527.4	1095.1x615.5	1209.6x680.4	1538.8*865.6
Display Rate	16:09	16:09	16:09	16:09	16:09
Max resolution	1920x1080	1920x1080	1920x1080	1920x1080	1920x1080
Display color	8 bit	10 bit	10 bit	10 bit	10 bit
Brightness (nits)	320cd/㎡	320cd/㎡	320cd/㎡	350cd/㎡	470cd/㎡
Contrast	1400:1	4000:1	4000:1	4000:1	1400:1
Visual angle	±178°	±178°	±176°	±176°	±176°
Response time	8ms	6.5ms	6.5ms	6.5ms	6.5ms
Speaker	MAX power: 15W*2
Mainboard
TV System	PAL, NTSC/SECAM (Optional)
	Input:  RFx1,Y Pb Pr *1; CVBS*2; CVBS Audio L/R *2; PC Audio*1; VGA*1; Media USB2.0*1; HDMI*1; HDMI built-in *1
	Output:  Earphone*1； AV*1;  HDMI*1； HDMI built-in *1; PC USB*2
	Buttons on side frame：POW、IN、MENU、VOL+、VOL-、CH+、CH-、PC
	Input on side frame:  USB2.0 *2
OPS COMPUTER
CPU	Intel Core i7/i5/i3 processor, intel H81 chipset
Memory	DDR3 1600Mhz 4G/8G option
SSD	120G SSD (240G SSD or 500G HDD option)
Wi-Fi	Optional, Wi-Fi with Antenna, 802.11 b/g/n
PC Ports	HDMI*1, RS232*1, LAN*1, USB3.0*2, USB2.0*4, WIFI with antenna
Touch Technology
Multi Touch	Infrared technology, support 10point ~32point touch; finger or any objects touch
Glass	Tempered glass, 4mm, Transparency rate>95%; 32768(W) × 32768(D) ;
Resolution	Response speed: 5ms;  Typical accuracy<1.5mm;Cursor Speed:180 d/s around;
Features	No drift, drive-free, waterproof, anti-dust; finger/object multi-touch, intelligence gesture recognizes etc
OS	Support Windows 7/ Windows 8
Whiteboard Software	Option, widely used to education, conference, military etc; multi-functions and multi-languages; compatible with Windows OS
Power supply
Power supply	AC100~240V 50 /60 HZ; Consumption: Standby<1W
Consumption	≦60W	≦80W	≦100W	≦120W	≦250W
Environments	Working: 0°C to 40°C ;Storage:-20°C to 55°C;  Humidity:20%-80% RH at 40°C, non-condensing
Physical Features
Case	Black color/ Aluminum alloy/ metal case
Dimension	795.4*490*116	1018.4*606.5*72.8	1174.9*697.3*73.27	1287.9*761.4*73.2
Package (mm)	890*575*210	1150*730*225	1325*835*235	1495*925*235
N/W & G/W (kg)	23 & 28kg	29 & 36kg	30 & 38kg	54 & 65kg	79 & 94kg
Accessories	ISO9001, CCC, CE, FCC
	User Guide, Warranty card, Remote Control, USB Cable 3m; Power Cable 1.5m; Touch Pens /2pcs,

The package will be settled by wooden case or pallet to ensure the shipment safety,. ITATOUCH will keep communicate with our clients to arrange all, include Air (by express or airport) and Ocean shipment.

Q: Which accessories would be included for the package of this interactive touch panel?

R:  the package accessories as below,



Q: What is the Lead-time?

R: Leadtime: within 10days for 1~10pcs.  around 10~20days for 20~100pcs.

Q: How long time is for the warranty?

R:  Usually it is one year.  Certainly, three years also except the sceen panel (since the factory of screen panel just offered one year). we could talk in case by case.

Q: How to order it?

R: Please send your inquiry , or call us. the process please refer the OEM / ODM service page.





Q: Does ITATOUCH provide the OS for the interactive touch screen with OPS PC ?

R:  Normally offer the finish device only, certainly we could help to install a tral version (WIN 7 / WIN 10) if needs, since we are the hardware interactive touch screen manufacturer.

Q: Is there extra whiteboard software for this interactive panel?

R: Yes, ITATOUCH could offer the whiteboard software if need,  or User could download it from website.

Company Features
1. Shenzhen ITA Touch Technology Co., LTD is a Chinese manufacturer of high quality touch screen video wall.
2. Equipped with a complete set of quality control technology, electrical display stand can be guaranteed with good quality.
3. ITATOUCH's devotion is to offer the most professional customer service which ranks top in smart interactive whiteboard industry. Contact!
